System And Components
478-3979 CONSOLE GP-OPERATORPART OF 473-2856 ELECTRICAL AR
Group No: 478-3979
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T6870 | 1 BOLT (M8X1.25X70-MM) | 1 | |
| 8T6912 | 2 BOLT (M8X1.25X50-MM) | 1 | |
| 3S2093 | 3 STRAP-CABLE | 5 | |
| 5P8500 | 4 KEY | 2 | |
| 6V9671 | 5 SCREW-MACHINE (M3X0.5X12-MM) | 4 | |
| 7K1181 | 6 STRAP-CABLE | 3 | |
| 8T4121 | 7 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4224 | 8 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 9X8256 | 9 WASHER (6.6X12X2-MM THK) | 6 | |
| 4678535 | 10 SWITCH AS-START (KEY) | 1 | |
| 7T6799 | NUT-MOUNTING (1-32-THD) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 1286157 | 11 PLATE | 1 | |
| 1336934 | 12 SPACER (11X20X25-MM THK) | 3 | |
| 1414976 | 13 SCREW-WASHER HEAD (4-40X0.5-IN) | 4 | |
| 1809900 | 14 CAP AS | 2 | |
| 5P7958 | SLEEVE-CABLE SPLICE | 1 | |
| 8C6354 | CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 1799392 | LANYARD | 1 | |
| 2098296 | 15 BOLT-SOCKET HEAD (M8X1.25X25-MM) | 6 | |
| 2321792 | 16 HORN (24-VOLT TO 12-VOLT)(ALARM) | 1 | |
| 2380251 | 17 SCREW-BUTTON HEAD (M10X1.5X25-MM) | 1 | |
| 3083527 | 18 SWITCH AS-TOGGLE (OPERATOR LADDER UP, DOWN) | 2 | |
| 3E3383 | WEDGE-RECEPTACLE LOCK (6-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 6 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 6T3632 | LOCKWASHER | 1 | |
| 6T3631 | NUT-HEX (15/32-32-THD) | 2 | |
| 6T3633 | RING-LOCKING | 1 | |
| 3445675 | 19 NUT (M10X1.5-THD) | 1 | |
| 3447618 | 20 COVER-SEAL | 1 | |
| 3518647 | 21 PLUG AS-CONNECTOR (12-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 12 | |
| 2418834 | PLUG AS-CONNECTOR (12-PIN) | 1 | |
| 4550709 | SEAL-CONNECTOR | 1 | |
| 3983073 | 22 CABLE AS | 1 | |
| 1552258 | WEDGE-PLUG LOCK (12-PIN) | 1 | |
| 1257876 | TUBE-HEAT SHRINK (17.78-MM DIA)(3-CM) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 4 | |
| 1690705 | PLUG-SEAL | 8 | |
| 3447617 | RECEPTACLE AS | 1 | |
| 3314222 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 5282427 | 23 GUARD GP-VANDALISM | 1 | |
| 2260294 | LOCK AS | 2 | |
| 2260338 | CAM | 2 | |
| 4646803 | 24 CONTROL GP-ELECTRONIC | 1 | |
| 5859423 | 25 PANEL GP-INSTRUMENT | 1 | |
| 5167058 | 26 HARNESS AS-CONSOLE | 1 | |
| 4866518 | 27 RESISTOR AS (PROPEL) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 1053486 | 28 BOLT-SOCKET HEAD (M6X1X50-MM) | 4 | |
| 1305300 | 29 CLIP | 6 | |
| 1772215 | 30 STRAP-DUAL CLAMP | 2 | |
| 3445673 | 31 NUT (M6X1-THD) | 1 | |
| 3523968 | 32 CLIP (LADDER) | 1 | |
| 8T3991 | 33 SCREW-BUTTON HEAD (M6X1X20-MM) | 1 | |
| 3E6600 | 34 SEAL (9-CM) | ||
| 2039007 | 35 NUT (1-1/2-18-THD) | 1 |
