450-4715 PLATFORM GP-OPERATORPART OF 444-5440 SCREED AR, 444-5430 SCREED AR-FIXED

Group No: 450-4715
Part NumberPart NameQty
13871251 BUMPER2
32083502 DAMPER2
39506003 PLATE4
48539084 PAD8
48539045 PLATFORM AS2
8T3612NUT-WELD (M8X1.25-THD)2
43346386 PLATFORM AS (MAIN)1
43421597 SUPPORT (LH)1
43421608 SUPPORT (RH)1
45369459 DAMPER AS2
4490369DAMPER (2-M)
473941610 BRACKET2
096998611 BOLT (M12X1.75X55-MM)2
3T085213 LOCKNUT (M8X1.25-THD)2
5C726114 NUT (M8X1.25-THD)2
5P107615 WASHER-HARD (13.5X30X4-MM THK)4
5P411616 WASHER-HARD (8.8X20.5X2-MM THK)2
8T417917 BOLT (M12X1.75X20-MM)4
8T418918 BOLT (M8X1.25X20-MM)8
8T422320 WASHER-HARD (13.5X25.5X3-MM THK)4
8T422421 WASHER-HARD (8.8X16X2-MM THK)10
8T854922 LOCKNUT (M12X1.75-THD)2
