System And Components
452-2818 PLATFORM GP-OPERATORPART OF 477-8896 OPERATOR AR
Group No: 452-2818
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1U5004 | 1 SPRING | 1 | |
| 1337864 | 2 BUSHING | 2 | |
| 1966792 | 4 PLATE-COVER | 1 | |
| 1966793 | 5 SHIM (1-MM THK) | 3 | |
| 1966794 | 6 PLATE-SPACER | 1 | |
| 1966798 | 7 PAD | 1 | |
| 2564000 | 8 SPACER | 4 | |
| 2567669 | 9 PLATE | 4 | |
| 2869963 | 10 LATCH AS | 1 | |
| 2964090 | 11 HINGE AS | 2 | |
| 5227214 | 12 PLATFORM GP-OPERATOR | 1 | |
| 1966791 | 12A BEARING-FLANGE | 2 | |
| 4522831 | PLATFORM AS (RH) | 1 | |
| 4522839 | 13 HANDRAIL AS | 1 | |
| 4567938 | 14 SEAT GP | 1 | |
| 4624450 | 15 COVER AS (RH) | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 1788510 | PLATE-WELD | 1 | |
| 4628979 | 16 COVER | 1 | |
| 4628980 | 17 LOCK | 1 | |
| 4629532 | 18 PLATE | 1 | |
| 4629534 | 19 PLATE | 1 | |
| 1373626 | 20 BOLT-SPECIAL (M6X1X23.25-MM) | 1 | |
| 1661222 | 21 SCREW-BUTTON HEAD (M8X1.25X30-MM) | 4 | |
| 1983899 | 22 SCREW-BUTTON HEAD (M8X1.25X20-MM) | 12 | |
| 1H1200 | 23 PIN-SPRING | 1 | |
| 5P4116 | 24 WASHER-HARD (8.8X20.5X2-MM THK) | 8 | |
| 8T4121 | 25 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4122 | 26 WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 8T4137 | 27 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4186 | 28 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4189 | 29 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4224 | 30 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 8C8585 | 31 SCREW-BUTTON HEAD (M10X1.5X20-MM) | 4 |
