System And Components
456-7938 SEAT GPPART OF 452-2818, 452-2819 PLATFORM GP-OPERATOR
Group No: 456-7938
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5123331 | 1 SEAT-CUSHION | 1 | |
| 5115544 | 2 ABSORBER-SHOCK | 1 | |
| 5123333 | 3 CUSHION-BACK | 1 | |
| 5123334 | 4 KIT-ARMREST | 1 | |
| 9M1974 | 5 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9X2616 | 6 SCREW-SOCKET (M8X1.25X16-MM) | 8 | |
| 5122229 | 7 NUT-SQUARE | 12 | |
| 1357242 | 8 SCREW-SELF-TAPPING (M5X2.3X18.8-MM) | 10 | |
| 8T0328 | 9 WASHER-HARD (5.5X10X1-MM THK) | 10 | |
| 7W3447 | 10 SPACER (10.2X19.05X10.2-MM THK) | 4 | |
| 5123335 | 11 KIT-RAIL | 1 | |
| 5A3604 | 12 BOLT-SOCKET HEAD (M8X1.25X25-MM) | 4 | |
| 5123336 | 13 BOOT | 1 | |
| 2375121 | 14 BOLT-SOCKET HEAD (M8X1.25X16-MM) | 4 | |
| 9K5635 | 15 SCREW-TAPPING (8-18X1-IN) | 1 | |
| 5123337 | 16 SLIDER | 1 | |
| 5123338 | 17 BLOCK | 1 | |
| 5123339 | 18 SPRING | 2 | |
| 5123340 | 19 YOKE | 1 | |
| 8T0114 | 20 PIN-SPRING | 2 | |
| 5123341 | 21 BUSHING | 1 | |
| 7X0622 | 22 WASHER (13X24X2.5-MM THK) | 2 | |
| 3182605 | 23 PIN-SPRING | 1 | |
| 5123342 | 24 PIN AS | 1 | |
| 5123343 | 25 HANDLE | 1 | |
| 6V8491 | 26 RING-RETAINING | 1 | |
| 7S5757 | 27 RING-RETAINING | 2 | |
| 5123345 | 28 SLEEVE | 4 | |
| 5123346 | 29 BUMPER | 2 | |
| 5123347 | 30 BUMPER | 1 | |
| 2Y5829 | 31 NUT (M10X1.5-THD) | 1 | |
| 5123348 | 32 SLEEVE | 1 | |
| 5123349 | 33 KNOB | 1 | |
| 9R4872 | 34 CLIP | 2 | |
| 5123350 | 35 PIN | 1 | |
| 1013917 | 36 WASHER (10.5X21X2-MM THK) | 1 | |
| 5123351 | 37 PIN | 1 | |
| 5123332 | KIT-SEAT BELT | 1 | |
| 5123344 | KIT-ADJUSTER | 1 |
