System And Components
475-5211 PLANETARY GP-FINAL DRIVEPART OF 475-5210 DRIVE GP-FINAL
Group No: 475-5211
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V3938 | 1 BOLT (M10X1.5X20-MM) | 10 | |
| 4912137 | 2 COVER-PLANETARY | 1 | |
| 3119643 | 3 PAD | 1 | |
| 4912139 | 5 CARRIER GP-PLANETARY | 1 | |
| 4184436 | 6 RING | 4 | |
| 4184439 | 7 KIT-FINAL DRIVE | 4 | |
| 4184440 | 8 RING (PLANETARY) | 1 | |
| 5W7392 | 9 PLUG | 6 | |
| 5W1699 | 10 WASHER (18.2X23.8X1.5-MM THK) | 6 | |
| 4186793 | 11 BOLT-SOCKET HEAD (M20X1.5X70-MM) | 12 | |
| 4374912 | 12 KIT-SEAL | 1 | |
| 4184443 | 13 SHIM | 1 | |
| 4184444 | 14 SHAFT | 1 | |
| 4912140 | 15 DISC-FRICTION | 5 | |
| 4184446 | 16 DISC-FRICTION | 4 | |
| 4184447 | 17 RING | 1 | |
| 4184448 | 18 PISTON-BRAKE | 1 | |
| 4184451 | 19 SPRING | 21 | |
| 4184449 | 20 PLATE-RETAINER | 1 | |
| 7U3538 | 21 RING-RETAINING | 1 | |
| 2K4472 | 22 SEAL-O-RING | 1 | |
| 2K4473 | 23 RING-BACKUP | 1 | |
| 2K8256 | 24 RING-BACKUP | 1 | |
| 2K8257 | 25 SEAL-O-RING | 1 | |
| 3F5792 | 26 SEAL-O-RING | 1 | |
| 1924486 | 27 SEAL-O-RING | 1 | |
| 5172210 | 28 RING-BACKUP | 1 | |
| 4912138 | 29 GEAR-SUN | 1 |
