System And Components
423-2586 TAMPER GP-SCREEDPART OF 450-4711 TAMPER GP-SCREED
Group No: 423-2586
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2379960 | 1 CLIP (LADDER) | 2 | |
| 4232593 | 2 SUPPORT GP (TAMPER SHAFT, LH) | 1 | |
| 4232594 | 3 SHAFT AS | 1 | |
| 4232596 | 4 SUPPORT GP (TAMPER SHAFT) | 2 | |
| 4309319 | 5 SPACER | 8 | |
| 4445396 | 6 SUPPORT GP (TAMPER SHAFT, RH) | 1 | |
| 4445398 | 7 BAR-TAMPER | 1 | |
| 4445413 | 8 PLATE | 5 | |
| 6V5200 | 9 RING-RETAINING | 2 | |
| 8T6912 | 10 BOLT (M8X1.25X50-MM) | 4 | |
| 8T4171 | 11 BOLT (M6X1X12-MM) | 5 | |
| 8T4224 | 12 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 5P4116 | 13 WASHER-HARD (8.8X20.5X2-MM THK) | 2 |
