Assembly
100%

433-3185 TAMPER GP-SCREEDPART OF 450-4711 TAMPER GP-SCREED

Group No: 433-3185
Part NumberPart NameQty
23799601 CLIP (LADDER)2
42325932 SUPPORT GP (TAMPER SHAFT, LH)1
42325943 SHAFT AS (TAMPER)1
42325964 SUPPORT GP (TAMPER BAR)2
43093195 SPACER8
43250836 SUPPORT GP (TAMPER SHAFT, RH)1
43331927 COUPLING1
44453988 BAR-TAMPER1
44454139 PLATE5
448769010 MOTOR GP-HYDRAULIC (TAMPER)1
095093211 RING-RETAINING1
6V519212 BOLT-SOCKET HEAD (M8X1.25X30-MM)4
6V520013 RING-RETAINING2
8T417114 BOLT (M6X1X12-MM)5
8T422415 WASHER-HARD (8.8X16X2-MM THK)6
8T691216 BOLT (M8X1.25X50-MM)4
5P411617 WASHER-HARD (8.8X20.5X2-MM THK)2
