System And Components
433-3206 TAMPER GP-SCREEDPART OF 450-4711 TAMPER GP-SCREED
Group No: 433-3206
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2379960 | 1 CLIP (LADDER) | 2 | |
| 4232593 | 2 SUPPORT GP (TAMPER SHAFT, LH) | 1 | |
| 4232594 | 3 SHAFT AS | 1 | |
| 4232596 | 4 SUPPORT GP (TAMPER BAR) | 2 | |
| 4309319 | 5 SPACER | 8 | |
| 4333192 | 6 COUPLING | 1 | |
| 4333207 | 7 SUPPORT GP (TAMPER SHAFT) | 1 | |
| 4445397 | 8 BAR-TAMPER | 1 | |
| 4445413 | 9 PLATE | 5 | |
| 4487690 | 10 MOTOR GP-HYDRAULIC (TAMPER) | 1 | |
| 0950932 | 11 RING-RETAINING | 1 | |
| 6V5192 | 12 BOLT-SOCKET HEAD (M8X1.25X30-MM) | 4 | |
| 6V5200 | 13 RING-RETAINING | 2 | |
| 8T6912 | 14 BOLT (M8X1.25X50-MM) | 4 | |
| 8T4171 | 15 BOLT (M6X1X12-MM) | 5 | |
| 8T4224 | 16 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 5P4116 | 17 WASHER-HARD (8.8X20.5X2-MM THK) | 2 |
