System And Components
437-3451 TAMPER GP-SCREED -EXTENSION, RHPART OF 469-2209 TAMPER GP-SCREED
Group No: 437-3451
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4232593 | 1 SUPPORT GP (TAMPER SHAFT, LH) | 1 | |
| 4309319 | 2 SPACER | 8 | |
| 4333167 | 3 SHAFT | 1 | |
| 4333169 | 4 SUPPORT GP (TAMPER BAR) | 1 | |
| 4445396 | 5 SUPPORT GP (TAMPER SHAFT, RH) | 1 | |
| 4445413 | 6 PLATE | 3 | |
| 4490389 | 7 PLATE-WEAR | 1 | |
| 4518939 | 8 BAR-TAMPER | 1 | |
| 1271960 | 9 SCREW-FLAT HEAD (M6X1X16-MM) | 2 | |
| 6V5200 | 10 RING-RETAINING | 2 | |
| 8T4171 | 11 BOLT (M6X1X12-MM) | 3 | |
| 8T4224 | 12 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 8T6912 | 13 BOLT (M8X1.25X50-MM) | 2 |
