System And Components
450-4711 TAMPER GP-SCREEDPART OF 444-5440 SCREED AR
Group No: 450-4711
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3832898 | 1 KEY-RECTANGULAR | 2 | |
| 4232586 | 2 TAMPER GP-SCREED (MAIN, LH) | 1 | |
| 4309349 | 3 TAMPER GP-SCREED (EXTENSION, LH) | 1 | |
| 4333185 | 4 TAMPER GP-SCREED (MAIN, RH) | 1 | |
| 4333206 | 5 TAMPER GP-SCREED (EXTENSION, RH) | 1 | |
| 4445414 | 6 PLATE-WEAR (LH) | 1 | |
| 4445415 | 7 PLATE-WEAR (RH) | 1 | |
| 4445420 | 8 SHAFT AS | 1 | |
| 4516822 | 9 PLATE-WEAR (EXTERNAL) | 2 | |
| 1271960 | 10 SCREW-FLAT HEAD (M6X1X16-MM) | 16 | |
| 3293356 | 11 NUT (M12X1.75-THD) | 16 | |
| 5P1076 | 12 WASHER-HARD (13.5X30X4-MM THK) | 16 | |
| 8T4910 | 13 BOLT (M12X1.75X60-MM) | 8 | |
| 8T4244 | 14 NUT (M12X1.75-THD) | 8 | |
| 5P8245 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 0951207 | 16 NUT (M12X1.75-THD) | 16 |
