System And Components
485-3548 TAMPER GP-SCREEDPART OF 444-5439 EXTENSION AR-SCREED
Group No: 485-3548
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8489 | 1 FITTING-GREASE (1/8-27 PTF) | 8 | |
| 2432636 | 2 KEY-RECTANGULAR | 4 | |
| 3832898 | 3 KEY-RECTANGULAR | 4 | |
| 4390074 | 4 COUPLING GP-TORSIONAL | 4 | |
| 4390075 | SLEEVE | 1 | |
| 4390076 | HUB | 2 | |
| 4390077 | 5 SHAFT | 2 | |
| 4853549 | 6 TAMPER GP-SCREED (LH) | 1 | |
| 4881416 | 7 TAMPER GP-SCREED (RH) | 1 | |
| 0963001 | 8 SETSCREW-SOCKET (M5X0.8X6-MM) | 8 | |
| 3293356 | 9 NUT (M12X1.75-THD) | 8 | |
| 3B6552 | 10 ELBOW-PIPE | 4 | |
| 5P1076 | 11 WASHER-HARD (13.5X30X4-MM THK) | 16 | |
| 8T4244 | 12 NUT (M12X1.75-THD) | 4 | |
| 8T4910 | 13 BOLT (M12X1.75X60-MM) | 4 | |
| 0951207 | 14 NUT (M12X1.75-THD) | 8 |
