System And Components
501-0503 FAN GP-SUCTION -WITH AIR CONDITIONERS/N DYN1-UP
Group No: 501-0503
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1851911 | 1 BELT-SERPENTINE | 1 | |
| 2610428 | 2 PULLEY AS-IDLER | 1 | |
| 3072242 | BOLT (M10X1.5X45-MM) | 1 | |
| 2994732 | 3 PULLEY (8-GROOVE) | 1 | |
| 3528358 | 4 GUARD AS-FAN | 1 | |
| 3691255 | 5 TENSIONER | 1 | |
| 4260616 | 6 SPACER-FAN | 1 | |
| 4488167 | 7 FILM-INFORMATION (BELT ROUTING) | 1 | |
| 4543411 | 8 FAN (6-BLADE) | 1 | |
| 1783336 | 9 NUT-HEX FLANGE (M8X1.25-THD) | 4 | |
| 5P4116 | 10 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 6I4733 | 11 STUD (M8X1.25-THD) | 4 | |
| 8T4224 | 12 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 8T5091 | 13 BOLT (M8X1.25X20-MM) | 4 | |
| 8T7547 | 14 BOLT (M8X1.25X30-MM) | 4 |
