System And Components
490-5419 EXTENSION GP-EXHAUSTS/N DYN1-UP
Group No: 490-5419
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7X0579 | 1 WASHER-HARD (8.8X25.5X2-MM THK) | 4 | |
| 7X7729 | 2 WASHER (11X25X3-MM THK) | 7 | |
| 8T4136 | 3 BOLT (M10X1.5X25-MM) | 5 | |
| 8T4195 | 4 BOLT (M10X1.5X30-MM) | 2 | |
| 1272170 | 5 SCREW-TRUSS HEAD (M8X1.25X20-MM) | 4 | |
| 4175268 | 6 EXTENSION GP-EXHAUST | 1 | |
| 5024861 | 7 FILM-IDENTIFICATION (CIRCLE) | 1 | |
| 2089310 | 8 BOLT-FLANGE HEAD (M12X1.75X30-MM) | 7 | |
| 4699328 | 9 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 5835132 | 10 TUBE AS (EXHAUST) | 1 | |
| 3377304 | CLAMP-BAND | 1 | |
| 4912048 | 11 SUPPORT AS (TOP) | 1 | |
| 1599541 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4912049 | 12 SUPPORT AS (BOTTOM) | 1 | |
| 1599541 | NUT-WELD (M10X1.5-THD) | 1 | |
| 5023355 | 13 BRACKET | 1 | |
| 5234230 | 14 PLATE | 1 |
