System And Components
507-3855 LINES GP-FUELS/N DYN1-UP
Group No: 507-3855
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 9 | |
| 5P4116 | 2 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 7K1181 | 3 STRAP-CABLE | 1 | |
| 8R0721 | 4 SPACER (11X16X35-MM THK) | 1 | |
| 8T4185 | 5 BOLT (M10X1.5X50-MM) | 1 | |
| 8T4189 | 6 BOLT (M8X1.25X20-MM) | 1 | |
| 8T4196 | 7 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4201 | 8 BOLT-LOCKING (M10X1.5X20-MM) | 1 | |
| 8T4224 | 9 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 0858091 | 10 BOLT (M10X1.5X55-MM) | 1 | |
| 1757739 | 11 CLAMP | 1 | |
| 1803730 | 12 STRAINER-FUEL (FILLER NECK SCREEN) | 1 | |
| 2381844 | 13 ELBOW | 1 | |
| 3554624 | 14 FILM-INFORMATION (LOW SULFUR DIESEL FUEL) | 1 | |
| 4330933 | 15 CLAMP | 16 | |
| 0910081 | 16 SPACER (10.5X20X10-MM THK) | 1 | |
| 1514841 | 17 BLOCK | 1 | |
| 1875086 | 18 TEE | 1 | |
| 2062423 | 19 SADDLE-MOUNTING | 1 | |
| 2287089 | 20 SEAL-O-RING | 1 | |
| 3065494 | 21 CLIP (LOOP) | 1 | |
| 3120288 | 22 CLAMP | 2 | |
| 3550632 | 23 CONNECTOR-SPECIAL | 4 | |
| 3550633 | 24 COUPLER-QUICK DISCONNECT | 3 | |
| 3673564 | 25 PLATE | 1 | |
| 3743516 | 26 CLIP-PIPE | 1 | |
| 3896235 | 27 BRACKET AS | 1 | |
| 4231982 | 28 HOSE (8.6-IN) | ||
| 4231982 | 28A HOSE (27.2-IN) | ||
| 4231982 | 28B HOSE (18.9-IN) | ||
| 4231982 | 28C HOSE (63.8-IN) | ||
| 4231982 | 28D HOSE (41-IN) | ||
| 4231982 | 28E HOSE (0.4-IN) | ||
| 4231982 | 28F HOSE (0.4-IN) | ||
| 4231982 | 28G HOSE (0.4-IN) | ||
| 4231982 | 28H HOSE (0.4-IN) | ||
| 8C3681 | 31 HOSE-DRAIN (87-CM) | ||
| 5422325 | 34 TUBE | 1 | |
| 5422326 | 35 TUBE | 1 | |
| 5K8451 | 40 CLIP (LOOP) | 1 | |
| 5P9297 | 41 CLIP (LOOP) | 3 | |
| 8T4121 | 42 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4133 | 43 NUT (M10X1.5-THD) | 1 | |
| 8T7547 | 44 BOLT (M8X1.25X30-MM) | 2 | |
| 1602243 | 45 SLEEVE-ABRASION (6.7-IN) | ||
| 1602243 | 45A SLEEVE-ABRASION (4.7-IN) | ||
| 1602244 | 46 SLEEVE-ABRASION (11.4-IN) |
