System And Components
503-9067 INSTALLATION GP-COMMUNICATION -NETWORK MANAGERS/N DYN1-UP
Group No: 503-9067
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4946472 | 1 CONTROL GP-COMMUNICATION | 1 | |
| 7X6315 | STRAP AS-GROUND | 1 | |
| 5P6006 | TUBE-HEAT SHRINK (9.52-MM DIA)(0.1-M) | ||
| 2L8078 | TERMINAL-RING (14-GA TO 16-GA, 5/16-IN SCREW) | 1 | |
| 2L8075 | TERMINAL-RING (14-GA TO 16-GA, NO. 8 SCREW) | 1 | |
| 3S2093 | 2 STRAP-CABLE | 1 | |
| 7K1181 | 3 STRAP-CABLE | 6 | |
| 8C5607 | 4 MOUNT-ISOLATION | 8 | |
| 8C5608 | 5 SPACER (6.5X9.5X25.4-MM THK) | 4 | |
| 8T4138 | 6 BOLT (M6X1X20-MM) | 1 | |
| 8T4205 | 7 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 9X2042 | 8 SCREW-TRUSS HEAD (M6X1X12-MM) | 2 | |
| 9X2045 | 9 SCREW-TRUSS HEAD (M6X1X20-MM) | 2 | |
| 9X6165 | 10 WASHER (6.5X22X2.5-MM THK) | 5 | |
| 1293178 | 11 LOCKNUT (M6X1-THD) | 4 | |
| 4216456 | 12 PLATE AS | 1 | |
| 4216457 | 13 PLATE | 1 | |
| 5039068 | 14 HARNESS AS-CONTROL | 1 | |
| 2061345 | 15 STRAP-CABLE | 1 | |
| 2061346 | 16 STRAP-CABLE | 1 |
