500-9258 PANEL GP-FUSE -POWER DISTRIBUTIONS/N DYN1-UP

Group No: 500-9258
Part NumberPart NameQty
1Q19051 FUSE (25-AMPERE)3
9W14412 FUSE (15-AMPERE)2
9W14423 FUSE (10-AMPERE)1
9W14464 FUSE (20-AMPERE)4
11384905 FUSE (10-AMPERE)18
11384916 FUSE (15-AMPERE)11
14093787 RELAY AS (12-VOLT)(POSITION LAMP)1
14093787A RELAY AS (12-VOLT)(FRONT HORN)1
19277278 FUSE (30-AMPERE)2
23263139 FUSE (40-AMPERE)1
265802510 RELAY AS (12-VOLT)(IGNITION-1)1
265802510A RELAY AS (12-VOLT)(IGNITION-2)1
265802510B RELAY AS (12-VOLT)(ENGINE)1
395958411 FUSE (3-AMPERE)1
418036312 FUSE (50-AMPERE)2
515820013 RELAY AS (12-VOLT)(START RELAY)1
1167471PULLER-MINIFUSE1
