System And Components
433-4681 SENSOR GP-ENGINES/N W7N1-UP
Group No: 433-4681
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1243815 | 1 BOLT (M8X1.25X16-MM) | 2 | |
| 1999252 | 2 SEAL-O-RING | 2 | |
| 1999267 | 3 SEAL-O-RING | 5 | |
| 1999751 | 4 SEAL-O-RING | 1 | |
| 2179039 | 5 STRAP-CABLE | 2 | |
| 2566454 | 6 SENSOR-TEMPERATURE (2-PIN)(COOLANT) | 1 | |
| 2566454 | 6A SENSOR-TEMPERATURE (2-PIN)(INTAKE MANIFOLD AIR) | 1 | |
| 2741639 | 7 SEAL | 2 | |
| 2765603 | 8 SEAL-O-RING | 1 | |
| 3203060 | 9 SENSOR GP-PRESSURE (ENGINE OIL) | 1 | |
| 3203061 | 10 SENSOR GP-PRESSURE (NRS INLET) | 1 | |
| 3203062 | 11 SENSOR GP-PRESSURE (INTAKE MANIFOLD AIR) | 1 | |
| 3203063 | 12 SENSOR GP-PRESSURE (ATMOSPHERIC AIR) | 1 | |
| 3113857 | 13 SENSOR-SPEED (PRIMARY, TIMING) | 1 | |
| 3113857 | 13A SENSOR-SPEED (SECONDARY, TIMING) | 1 | |
| 3851174 | 14 SENSOR GP-PRESSURE (NRS OUTLET) | 1 | |
| 4321403 | 15 MANIFOLD AS | 1 | |
| 4662880 | 16 HOSE | 1 | |
| 4662881 | 17 HOSE | 1 | |
| 4536510 | 18 UNION | 3 | |
| 4536997 | 19 UNION | 1 | |
| 4548813 | 20 CLAMP | 4 | |
| 6I0254 | 21 BOLT (M8X1.25X30-MM) | 2 | |
| 3017012 | 22 SCREW-PAN HEAD (M6X1X20-MM) | 4 | |
| 4743231 | 23 SENSOR AS-TEMPERATURE (2-PIN)(NOX REDUCTION SYSTEM) | 1 | |
| 2818802 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 4543966 | KIT-HOSE | 1 | |
| 4543970 | KIT-HOSE | 1 |
