System And Components
Assembly
100%

496-3702 HOOD & GUARD GPS/N DYN1-UP

Group No: 496-3702
Part NumberPart NameQty
13019161 STUD-BALL (M8X1.25X20-MM)6
10171782 BOLT (M10X1.5X55-MM)2
11492843 BUMPER2
12721704 SCREW-TRUSS HEAD (M8X1.25X20-MM)4
17833365 NUT-HEX FLANGE (M8X1.25-THD)4
19838996 SCREW-BUTTON HEAD (M8X1.25X20-MM)2
25068587 LATCH AS (HOOD)1
34299138 BOLT-FLANGE HEAD (M10X1.5X20-MM)6
34456749 NUT (M8X1.25-THD)2
351474610 FILM-IDENTIFICATION (CAT)1
357427311 HOOD (RH)1
357427412 HOOD (LH)1
399834713 CABLE AS1
417424214 SPRING1
417432815 BRACKET AS1
1599540NUT-WELD (M8X1.25-THD)2
420486816 LOCK AS1
474058517 BUMPER AS (RH)1
474058618 BUMPER AS (LH)1
476904919 SPRING AS-GAS2
496346620 GUARD AS1
1599540NUT-WELD (M8X1.25-THD)2
496369921 PLATE AS1
1599540NUT-WELD (M8X1.25-THD)13
1599541NUT-WELD (M10X1.5-THD)2
526448422 GRILL GP-RADIATOR1
547548623 GROMMET1
5P411624 WASHER-HARD (8.8X20.5X2-MM THK)6
7X253725 BOLT (M8X1.25X35-MM)2
7Y909926 SCREW-TRUSS HEAD (M8X1.25X25-MM)4
9G130727 GROMMET1
292289628 CONDUIT (16.9-MM ID)(40-CM)
220073829 SEAL (52-CM EACH)
220073829A SEAL (11-CM EACH)
220073829B SEAL (5-CM EACH)
