System And Components
542-8980 MODULE GP-COOLINGS/N JHR1-UP
Group No: 542-8980
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0964035 | 1 CLIP | 1 | |
| 1757141 | 2 NUT-HEX FLANGE (M10X1.5-THD) | 4 | |
| 2606685 | 3 WASHER (9X25X1.6-MM THK) | 3 | |
| 3570003 | 4 PIN | 8 | |
| 5529247 | 5 MOUNT AS | 1 | |
| 5753963 | 6 KIT-SEAL | 1 | |
| 5753964 | 7 KIT-SEAL | 1 | |
| 5753965 | 8 KIT-SEAL | 1 | |
| 5753966 | 9 SEAL-AIR | 1 | |
| 5753967 | 10 KIT-SEAL | 1 | |
| 5753968 | 11 KIT-SEAL | 1 | |
| 5753969 | 12 KIT-SEAL | 1 | |
| 5753970 | 13 KIT-SEAL | 1 | |
| 5753971 | 14 SEAL-AIR | 1 | |
| 5753972 | 15 KIT-SEAL | 1 | |
| 5753973 | 16 FRAME AS-BOTTOM | 1 | |
| 5753974 | 17 FRAME AS | 1 | |
| 5753975 | 18 FRAME AS | 1 | |
| 5753976 | 19 FRAME AS | 1 | |
| 5753977 | 20 FRAME AS | 1 | |
| 5753978 | 21 FRAME AS | 1 | |
| 5753979 | 22 BRACKET AS | 1 | |
| 5753980 | 23 CORE AS-OIL COOLER | 1 | |
| 5753981 | 24 CORE AS-AFTERCOOLER | 1 | |
| 5753982 | 25 FUEL | 1 | |
| 5753983 | 26 CORE AS-RADIATOR | 1 | |
| 6V9027 | SEAL-O-RING | 1 | |
| 1549023 | VALVE-SAMPLING | 1 | |
| 1570670 | CAP-DUST | 1 | |
| 5753984 | VALVE (SHUNT) | 1 | |
| 5753986 | DRAIN AS | 1 | |
| 5753985 | 27 SHROUD AS | 1 | |
| 7X2546 | 28 BOLT (M10X1.5X180-MM) | 4 | |
| 7X7729 | 29 WASHER (11X25X3-MM THK) | 4 | |
| 8T4121 | 30 WASHER-HARD (11X21X2.5-MM THK) | 29 | |
| 8T4136 | 31 BOLT (M10X1.5X25-MM) | 21 | |
| 8T4137 | 32 BOLT (M10X1.5X20-MM) | 8 | |
| 8T4189 | 33 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4200 | 34 BOLT (M8X1.25X16-MM) | 14 | |
| 8T4224 | 35 WASHER-HARD (8.8X16X2-MM THK) | 18 | |
| 8T4908 | 36 BOLT (M8X1.25X25-MM) | 2 | |
| 8T7547 | 37 BOLT (M8X1.25X30-MM) | 1 | |
| 7Y1976 | 38 HOSE-WATER (15-CM) |
