System And Components
540-3113 SENSOR GP-ENGINES/N J361-UP
Group No: 540-3113
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1999267 | 1 SEAL-O-RING | 1 | |
| 2741639 | 2 SEAL (FUEL SYSTEM) | 2 | |
| 1004838 | 3 BOLT (M6X1X20-MM) | 1 | |
| 1127704 | 4 BOLT (M6X1X30-MM) | 2 | |
| 2179039 | 5 STRAP-CABLE | 3 | |
| 2566454 | 6 SENSOR-TEMPERATURE (2-PIN)(COOLANT) | 1 | |
| 4743231 | 7 SENSOR AS-TEMPERATURE (2-PIN) | 1 | |
| 2818802 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 4815928 | 8 SENSOR-SPEED (CAMSHAFT) | 1 | |
| 4815928 | 8A SENSOR-SPEED (CRANKSHAFT) | 1 | |
| 5003341 | 9 SENSOR AS-TEMP & PRESS (INLET MANIFOLD) | 1 | |
| 5172398 | SEAL-O-RING | 1 | |
| 5130267 | 10 SENSOR GP-PRESSURE (FUEL) | 1 | |
| 3410643 | SEAL-RECTANGULAR | 2 | |
| 5298053 | 11 SWITCH AS-PRESSURE (OIL) | 1 | |
| 5424656 | 12 SENSOR AS-TEMPERATURE (AIR) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1999751 | 13 SEAL-O-RING | 1 | |
| 6I0572 | 14 BOLT (M8X1.25X20-MM) | 2 |
