System And Components
489-7848 WIRING GP-CABS/N NFZ1-UP
Group No: 489-7848
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 29 | |
| 7K1181 | 2 STRAP-CABLE | 6 | |
| 1495050 | 3 RELAY (24-VOLT)(MAIN POWER) | 1 | |
| 1495050 | 3A RELAY (24-VOLT)(DEF PUMP) | 1 | |
| 1495050 | 3B RELAY (24-VOLT)(PRIMING PUMP) | 1 | |
| 1495050 | 3C RELAY (24-VOLT)(FUEL PUMP) | 1 | |
| 1495050 | 3D RELAY (24-VOLT)(ETHER) | 1 | |
| 1495050 | 3E RELAY (24-VOLT)(KEEP ALIVE) | 2 | |
| 1495050 | 3F RELAY (24-VOLT)(KEY) | 1 | |
| 2702679 | 4 LOCKWASHER | 1 | |
| 3245682 | 5 PANEL AS | 1 | |
| 3245683 | SEAL | 1 | |
| 3279955 | 6 CAP (1-PIN CONNECTOR) | 1 | |
| 3355365 | 7 SOCKET-AUXILIARY POWER (12-VOLT) | 1 | |
| 4319515 | 8 LAMP GP-DOME (12/24-VOLT, LED) | 1 | |
| 4849066 | 9 FUSE AS (KEEP ALIVE) | 1 | |
| 7Y3952 | PLUG-CONNECTOR (2-PIN) | 2 | |
| 7Y3993 | TERMINAL-BLADE (12-GA) | 2 | |
| 1243548 | FUSE (30-AMPERE)(KEEP ALIVE) | 1 | |
| 0965962 | 10 WASHER-HARD (3.4X7X0.8-MM THK) | 1 | |
| 0966166 | 11 WASHER-HARD (4.5X9X1-MM THK) | 2 | |
| 1636795 | 12 STRAP-CABLE | 1 | |
| 1673593 | 13 STRAP | 1 | |
| 2039007 | 14 NUT (1-1/2-18-THD) | 1 | |
| 2042281 | 15 STRAP-CABLE | 3 | |
| 2510637 | 16 INSULATION | 19 | |
| 2725841 | 17 RELAY (70-AMPERE)(MAIN) | 1 | |
| 3C6969 | 18 NUT (M3X0.5-THD) | 1 | |
| 4279771 | 19 TIE | 3 | |
| 4841456 | 20 STRAP-CABLE | 1 | |
| 4900579 | 21 ADAPTER AS | 4 | |
| 4900585 | 22 ADAPTER AS | 3 | |
| 4900588 | 23 NUT (PANEL) | 7 | |
| 4903875 | 24 CABLE AS (CAB) | 1 | |
| 3280111 | PIN-CONNECTOR | 1 | |
| 3245685 | RECEPTACLE AS-CONNECTOR (1-PIN) | 1 | |
| 9G4343 | TERMINAL-RING (4-GA, 1/4-IN SCREW) | 1 | |
| 6V2369 | CABLE (4-GA, BLACK)(0.4-M) | ||
| 4917831 | 25 BASE | 17 | |
| 4922010 | 26 PANEL AS | 1 | |
| 4922012 | 27 TIE | 3 | |
| 4940022 | 28 BASE AS (ANTENNA) | 1 | |
| 5057637 | 29 PLUG AS-CONNECTOR (2-PIN) | 4 | |
| 1690705 | PLUG-SEAL | 2 | |
| 4900571 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 5057638 | 30 PLUG AS-CONNECTOR (2-PIN) | 3 | |
| 4900578 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 1690705 | PLUG-SEAL | 2 | |
| 5065911 | 31 LOCK-CONNECTOR | 2 | |
| 5157178 | 32 BRACKET | 1 | |
| 5248403 | 33 BRACKET AS | 1 | |
| 5248405 | 34 BRACKET AS | 1 | |
| 5248408 | 35 BRACKET AS | 1 | |
| 5281514 | 36 SPEAKER AS | 2 | |
| 7Y3951 | TERMINAL-BLADE (14-GA) | 2 | |
| 7Y3954 | CONNECTOR-PLUG (3-PIN) | 1 | |
| 5590169 | 37 WIRING GP-CAB | 1 | |
| 5432650 | 38 HARNESS AS-CAB (ROOF) | 1 | |
| 1230707 | 39 SCREW-HEX SOCKET (M4X0.7X20-MM) | 2 | |
| 6V9669 | 40 SCREW-MACHINE (M3X0.5X8-MM) | 1 | |
| 7I2272 | 41 BOLT (M5X0.8X12-MM) | 1 | |
| 8T0328 | 42 WASHER-HARD (5.5X10X1-MM THK) | 1 | |
| 8T0337 | 43 SCREW-MACHINE (M4X0.7X12-MM) | 8 | |
| 8T4121 | 44 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4198 | 45 BOLT (M10X1.5X100-MM) | 3 | |
| 9X2042 | 46 SCREW-TRUSS HEAD (M6X1X12-MM) | 21 | |
| 9X2043 | 47 SCREW-TRUSS HEAD (M6X1X14-MM) | 8 | |
| 3279954 | 48 CAP (12-PIN CONNECTOR) | 1 |
