System And Components
556-9704 WIRING GP-CHASSISS/N NFZ1-UP
Group No: 556-9704
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2042281 | 1 STRAP-CABLE | 2 | |
| 7X2621 | 2 BOLT (M10X1.5X12-MM) | 1 | |
| 8T4182 | 3 BOLT (M10X1.5X45-MM) | 5 | |
| 7X2548 | 4 BOLT (M12X1.75X16-MM) | 1 | |
| 8T4172 | 5 BOLT (M10X1.5X80-MM) | 2 | |
| 8T4189 | 6 BOLT (M8X1.25X20-MM) | 1 | |
| 0996418 | 7 NUT (M6X1-THD) | 1 | |
| 1321805 | 8 STRAP AS-GROUND | 1 | |
| 1467112 | 9 GROMMET | 2 | |
| 1673583 | 10 STRAP AS-GROUND | 1 | |
| 1772215 | 11 STRAP-DUAL CLAMP | 1 | |
| 2369241 | 12 GROMMET | 1 | |
| 2418368 | 13 SWITCH GP-MAGNETIC (24-VOLT)(GLOW PLUG RELAY) | 1 | |
| 2667379 | 14 STRAP-CABLE | 2 | |
| 2G8767 | 15 WASHER (10.5X60X3-MM THK) | 9 | |
| 3280132 | 16 CABLE AS | 1 | |
| 9G0002 | COVER AS-TERMINAL (RED) | 1 | |
| 9G0005 | COVER AS-TERMINAL (BLACK) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 8C5918 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 8T9756 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 1598049 | CABLE (00-GA, RED)(31-CM) | ||
| 3445674 | 17 NUT (M8X1.25-THD) | 1 | |
| 3S2093 | 18 STRAP-CABLE | 51 | |
| 4837800 | 19 SPACER (11X20X20-MM THK) | 3 | |
| 4837806 | 20 SPACER (11X20X56-MM THK) | 2 | |
| 5757309 | 21 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 4841451 | 22 CLIP | 27 | |
| 4841452 | 23 CLIP | 2 | |
| 4841454 | 24 CLIP-RETAINING | 16 | |
| 4841456 | 25 STRAP-CABLE | 42 | |
| 4B4277 | 26 WASHER (8.8X17.5X1.6-MM THK) | 2 | |
| 5080558 | 27 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 3 | |
| 5242769 | 28 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 5244506 | 29 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 5572120 | 30 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 5572122 | 31 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 5572124 | 32 PLATE AS | 1 | |
| 8Y3795 | BOSS (M10X1.5X40-MM) | 1 | |
| 9R2672 | BOSS-THREADED (M10X1.5X20-MM) | 1 | |
| 5572126 | 33 STRAP AS-GROUND | 1 | |
| 0350425 | RING-TERMINAL (000-GA, 3/8-IN SCREW) | 1 | |
| 3900853 | TERMINAL-RING | 1 | |
| 5573382 | 34 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 5588887 | 35 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 5588888 | 36 BRACKET AS | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 5593150 | 37 BRACKET AS-VALVE | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 5593156 | 38 LINER | 1 | |
| 5599646 | 39 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 5604083 | 40 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 5733596 | 41 PLATE AS-FUSE | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 3 | |
| 5733600 | 42 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 5733603 | 43 PLATE | 1 | |
| 5759377 | 44 BLOCK AS-FUSE | 1 | |
| 5765225 | 45 CABLE AS | 1 | |
| 6V2369 | CABLE (4-GA, BLACK)(1.7-M) | ||
| 5P3454 | TERMINAL-RING (4-GA, 5/16-IN SCREW) | 1 | |
| 2042281 | STRAP-CABLE | 1 | |
| 3245824 | PLUG AS-CONNECTOR (1-PIN) | 1 | |
| 3245825 | SOCKET-CONNECTOR (4-GA) | 1 | |
| 4841452 | CLIP | 1 | |
| 5765226 | 46 CABLE AS-BATTERY (POSITIVE) | 1 | |
| 6V2722 | TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M) | ||
| 8N1725 | COVER AS-TERMINAL (RED) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 3S6049 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 0301705 | TERMINAL-CABLE (00-GA, 5/16-IN SCREW) | 1 | |
| 1598049 | CABLE (00-GA, RED)(63-CM) | ||
| 5765227 | 47 CABLE AS-BATTERY (NEGATIVE) | 1 | |
| 7N5274 | COVER AS-TERMINAL (BLACK) | 1 | |
| 8L8413 | STRAP-CABLE (WHITE) | 1 | |
| 3S6050 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 1598050 | CABLE (00-GA, BLACK)(44-CM) | ||
| 2999092 | COVER-TERMINAL (BLACK) | 1 | |
| 3150180 | TERMINAL-RING (00-GA, 3/8-IN SCREW) | 1 | |
| 5765228 | 48 CABLE AS (DISCONNECT) | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 2 | |
| 6V2722 | TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M) | ||
| 1598050 | CABLE (00-GA, BLACK)(23-CM) | ||
| 5765232 | 49 WIRE AS (GLOW PLUG RELAY) | 1 | |
| 5766849 | 50 HARNESS AS-CAB (PRODUCT LINK 243, 083) | 1 | |
| 5766917 | 51 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 5814077 | 52 CABLE AS-STARTER (STARTER) | 1 | |
| 6V2722 | TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M) | ||
| 1598049 | CABLE (00-GA, RED)(188-CM) | ||
| 2042281 | STRAP-CABLE | 1 | |
| 2761786 | COVER-TERMINAL (RED) | 1 | |
| 3150180 | TERMINAL-RING (00-GA, 3/8-IN SCREW) | 1 | |
| 3841357 | TERMINAL-RING | 1 | |
| 4841452 | CLIP | 1 | |
| 5814078 | 53 CABLE AS (ALTERNATOR) | 1 | |
| 6V2722 | TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M) | ||
| 8T8827 | BOOT (RED) | 1 | |
| 0301708 | TERMINAL-RING (0-GA) | 2 | |
| 1598047 | CABLE-ELECTRICAL (0-GA, RED)(206-CM) | ||
| 2042281 | STRAP-CABLE | 1 | |
| 4841452 | CLIP | 1 | |
| 5817834 | 54 WIRE AS (GLOW PLUG RELAY) | 1 | |
| 5824367 | 55 BRACKET AS (ENGINE) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 8Y3795 | BOSS (M10X1.5X40-MM) | 1 | |
| 5825480 | 56 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 5829882 | 57 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 5907516 | 58 HARNESS AS-CHASSIS | 1 | |
| 5907518 | 59 WIRE AS (STARTER) | 1 | |
| 5907519 | 60 WIRE AS (STARTER) | 1 | |
| 5P4116 | 61 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 6G2256 | 62 CLAMP | 5 | |
| 6G2263 | 63 SPACER (10.5X19X28.5-MM THK) | 5 | |
| 7I2673 | 64 STRAP-CABLE | 6 | |
| 7K1181 | 65 STRAP-CABLE | 17 | |
| 8T4121 | 66 WASHER-HARD (11X21X2.5-MM THK) | 63 | |
| 8T4136 | 67 BOLT (M10X1.5X25-MM) | 14 | |
| 8T4137 | 68 BOLT (M10X1.5X20-MM) | 39 | |
| 8T4138 | 69 BOLT (M6X1X20-MM) | 4 | |
| 1837121 | 70 BOLT (M10X1.5X35-MM) | 4 | |
| 8T4223 | 71 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4224 | 72 WASHER-HARD (8.8X16X2-MM THK) | 7 | |
| 8T4908 | 73 BOLT (M8X1.25X25-MM) | 3 | |
| 8T6466 | 74 BOLT (M10X1.5X60-MM) | 2 | |
| 9R7941 | 75 SOCKET AS | 1 | |
| 9R7980 | COVER | 1 | |
| 9X2042 | 76 SCREW-TRUSS HEAD (M6X1X12-MM) | 2 | |
| 9X8256 | 77 WASHER (6.6X12X2-MM THK) | 4 |
