System And Components
507-1118 DRIVE GP-FINAL -WITHOUT MOTORS/N NFZ1-UP
Group No: 507-1118
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5329411 | 1 SEAL GP-DUO-CONE | 1 | |
| 5329412 | 2 HOUSING | 1 | |
| 5329415 | 3 CARRIER-PLANETARY | 1 | |
| 5329416 | 4 GEAR-SUN | 1 | |
| 5329417 | 5 GEAR-PLANETARY | 3 | |
| 5329418 | 6 CARRIER-PLANETARY | 1 | |
| 5329419 | 7 GEAR-SUN | 1 | |
| 5329420 | 8 GEAR-PLANETARY | 4 | |
| 5329421 | 9 WASHER (58.5X80X3.8-MM THK) | 4 | |
| 5329422 | 10 PLATE | 2 | |
| 5329423 | 11 COVER | 1 | |
| 5329424 | 12 PLATE | 2 | |
| 5329425 | 13 SHIM | 1 | |
| 5329426 | 14 BEARING | 2 | |
| 5329427 | 15 RACE-INNER | 3 | |
| 5329428 | 16 RACE-INNER | 4 | |
| 5329429 | 17 BEARING-NEEDLE | 3 | |
| 5329430 | 18 BEARING-NEEDLE | 4 | |
| 0931322 | 19 PLUG | 2 | |
| 0951585 | 20 SEAL-O-RING | 2 | |
| 1053478 | 21 BOLT-SOCKET HEAD (M10X1.5X35-MM) | 12 | |
| 5329433 | 22 BALL | 1 | |
| 8T4179 | 23 BOLT (M12X1.75X20-MM) | 4 |
