System And Components
509-5929 MOTOR GP-TRAVELS/N NFZ1-UP
Group No: 509-5929
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5384275 | 1 SEAL-O-RING | 1 | |
| 1903010 | 2 SEAL-O-RING | 1 | |
| 5365550 | 3 HOUSING | 1 | |
| 5365534 | 4 PISTON AS | 1 | |
| 5365537 | 5 PLATE-RETAINER | 1 | |
| 5365538 | 6 GUIDE-BALL | 1 | |
| 5365535 | 7 SHAFT-DRIVE | 1 | |
| 5365548 | 8 KEY | 2 | |
| 5384280 | 9 DOWEL | 4 | |
| 5384277 | 10 BEARING | 1 | |
| 5384274 | 11 SEAL-LIP TYPE | 1 | |
| 5365549 | 12 SPRING | 1 | |
| 5365547 | 13 PISTON | 1 | |
| 5365536 | 14 SWASHPLATE | 1 | |
| 5384279 | 15 ROLLER-NEEDLE | 3 | |
| 5365540 | 16 SEAT-SPRING | 2 | |
| 5365544 | 17 PLATE-FRICTION | 3 | |
| 5365545 | 18 PLATE-SEPARATOR | 3 | |
| 5365541 | 19 PISTON-BRAKE | 1 | |
| 9S8004 | 20 PLUG (9/16-18-THD) | 2 | |
| 9F1399 | 21 SEAL-O-RING | 1 | |
| 5365539 | 22 PLATE-VALVE | 1 | |
| 5384276 | 23 RING-RETAINING | 1 | |
| 5365546 | 24 SHIM AS | 2 | |
| 5384278 | 25 BEARING | 1 | |
| 5365543 | 26 SPRING | 1 | |
| 0993095 | 27 DOWEL | 1 | |
| 5365542 | 28 SPRING-BRAKE | 11 | |
| 5365552 | 29 VALVE GP-TRAVEL COUNTERBALANCE (TRACTION CONTROL) | 1 | |
| 8T3957 | 30 BOLT-SOCKET HEAD (M12X1.75X30-MM) | 10 | |
| 9X6154 | 31 BOLT-SOCKET HEAD (M8X1.25-THD) | 4 | |
| 5365533 | 32 VALVE GP-RELIEF | 1 |
