System And Components
556-6509 BOX GP-STORAGES/N NFZ1-UP
Group No: 556-6509
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1785576 | 1 STOP | 2 | |
| 5103135 | 2 LOCK AS | 1 | |
| 5167395 | 3 SPRING AS-GAS | 2 | |
| 5266001 | 4 COVER AS-BOX | 1 | |
| 3D9143 | HINGE-BUTT | 2 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 3 | |
| 8T5413 | STUD-WELD (M10X1.5X25-MM) | 2 | |
| 5277671 | 5 STRIKER AS | 1 | |
| 5277673 | 6 SHIM (0.5-MM THK) | 4 | |
| 5277674 | 7 SHIM (1-MM THK) | 2 | |
| 5566511 | 8 BOX AS-STORAGE | 1 | |
| 1019848 | SEAL (0.4-M) | ||
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 5C7261 | 9 NUT (M8X1.25-THD) | 4 | |
| 5P4116 | 10 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4133 | 12 NUT (M10X1.5-THD) | 4 | |
| 8T4138 | 13 BOLT (M6X1X20-MM) | 3 | |
| 8T4224 | 14 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 8T7547 | 15 BOLT (M8X1.25X30-MM) | 2 | |
| 9X8256 | 16 WASHER (6.6X12X2-MM THK) | 3 |
