System And Components
501-2402 GEAR & BEARING GP-SWINGS/N NFZ1-UP
Group No: 501-2402
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I7446 | 1 GASKET | 1 | |
| 2276186 | 2 SPACER (16.6X32X26-MM THK) | 40 | |
| 3576019 | 3 BOLT (M16X2X70-MM) | 40 | |
| 4685307 | 4 SPACER (16.6X32X5-MM THK) | 37 | |
| 5009135 | 5 RETAINER | 1 | |
| 5011010 | 6 BOOT | 1 | |
| 5580411 | 7 GEAR & BEARING GP-SWING | 1 | |
| 3B8489 | FITTING-GREASE (1/8-27 PTF) | 2 | |
| 1484685 | SEAL (309-CM) | ||
| 2291078 | SEAL-DUST | 2 | |
| 5258121 | 8 BOLT-HEAD (M16X2X85-MM) | 37 | |
| 0951299 | 9 DOWEL | 1 | |
| 4I7326 | 10 STRIP | 1 | |
| 5P3860 | 11 CLAMP-HOSE | 1 | |
| 8T4121 | 12 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4136 | 13 BOLT (M10X1.5X25-MM) | 12 | |
| 1U8846 | SEALANT-GASKET |
