System And Components
524-2693 CYLINDER & SEAL GP-STICKS/N NFZ1-UP
Group No: 524-2693
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8489 | 1 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 6V0357 | 2 SEAL-O-RING | 1 | |
| 0950703 | 3 BOLT-SOCKET HEAD (M16X2X75-MM) | 12 | |
| 1293181 | 4 BOLT-SOCKET HEAD (M10X1.5X55-MM) | 4 | |
| 2357679 | 5 SEAL-LIP TYPE | 4 | |
| 3852899 | 6 RING-RETAINING | 1 | |
| 3852900 | 7 BUSHING | 1 | |
| 3852919 | 8 STOP | 1 | |
| 3937935 | 9 RING-RETAINING | 1 | |
| 4161285 | 10 SEAL-U-CUP | 1 | |
| 4161287 | 11 SEAL-BUFFER | 1 | |
| 4229122 | 12 BALL | 1 | |
| 5103504 | 13 RING-WIPER | 1 | |
| 5103506 | 14 RING-BACKUP | 1 | |
| 5245825 | 15 CYLINDER AS | 1 | |
| 4893026 | 15A BEARING-SLEEVE | 1 | |
| 5245826 | 16 ROD AS | 1 | |
| 4893026 | 16A BEARING-SLEEVE | 1 | |
| 5568427 | 17 SETSCREW-SOCKET (M12X1.75X10-MM) | 1 | |
| 5581580 | 18 RING-RETAINING | 1 | |
| 5581581 | 19 PISTON | 1 | |
| 5581583 | 20 RING-WEAR | 2 | |
| 5581584 | 21 SEAL AS-PISTON | 1 | |
| 5581587 | 22 STOP | 1 | |
| 5581588 | 23 LOCKNUT-SPECIAL | 1 | |
| 5581589 | 24 HEAD | 1 | |
| 5581591 | 25 SEAL-O-RING | 1 | |
| 5581593 | 26 RING-BACKUP | 1 | |
| 5581600 | 27 RING-WEAR | 1 | |
| 5671781 | 28 ELBOW | 1 | |
| 5681095 | 29 RING-SEAL | 1 | |
| 5713206 | 30 RING-SEAL | 1 | |
| 5581594 | KIT-HYDRAULIC CYLINDER | 1 |
