System And Components
560-3993 DRIVE GP-SWING -WITHOUT MOTORS/N NFZ1-UP
Group No: 560-3993
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5658953 | 1 SHAFT-PINION (11-TEETH) | 1 | |
| 5658954 | 2 SPACER (85X115X2-MM THK) | 1 | |
| 5658957 | 3 COVER | 1 | |
| 5658958 | 4 BEARING | 1 | |
| 3603679 | 5 PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 5658960 | 6 HOUSING | 1 | |
| 5658961 | 7 SEAL-RING | 1 | |
| 5658963 | 8 BEARING | 1 | |
| 5658964 | 9 SPACER (65.5X74.5X3.5-MM THK) | 1 | |
| 5658969 | 10 NUT (M65X2-THD) | 1 | |
| 5658992 | 11 CARRIER AS | 1 | |
| 5658973 | 12 GEAR-SUN (18-TEETH) | 1 | |
| 5658975 | 13 CARRIER AS | 1 | |
| 5658977 | 14 WASHER (30.2X46.7X1-MM THK) | 3 | |
| 5658978 | 15 GEAR-PLANETARY (26-TEETH) | 3 | |
| 5658982 | 16 ROLLER | 54 | |
| 5658984 | 17 WASHER (29X50X3-MM THK) | 3 | |
| 5658985 | 18 RING-RETAINING | 3 | |
| 5658987 | 19 GEAR-SUN (24-TEETH) | 1 | |
| 5658959 | 20 ADAPTER | 1 | |
| 4K6804 | 21 SEAL-O-RING | 1 | |
| 5658991 | 22 HOUSING | 1 | |
| 1364184 | 23 BOLT-SOCKET HEAD (M8X1.25X40-MM) | 2 | |
| 3J1907 | 24 SEAL-O-RING | 1 |
