Assembly
100%

558-1451 LINES GP-AUXILIARY HYDRAULIC -STICK, HIGH PRESSURES/N NFZ1-UP

Group No: 558-1451
Part NumberPart NameQty
8T41961 BOLT (M10X1.5X35-MM)4
8T46482 BOLT (M12X1.75X70-MM)8
1P37033 SEAL-RECTANGULAR4
6V04004 FLANGE-HALF4
6V97465 SEAL-O-RING1
7X05846 WASHER-HARD (13.5X20.5X2-MM THK)4
7Y37327 CLIP2
7Y48688 CLIP2
8T41399 BOLT (M12X1.75X30-MM)4
8T419410 BOLT (M12X1.75X50-MM)8
8T422311 WASHER-HARD (13.5X25.5X3-MM THK)16
8T793412 WASHER-HARD (11X21X5-MM THK)4
105347913 BOLT-SOCKET HEAD (M10X1.5X90-MM)4
282589414 VALVE GP-MANUAL (AUXILIARY, SHUTOFF)2
288769015 CLIP AS2
288769116 CLIP AS2
560397617 HOSE AS1
560397918 HOSE AS1
560398819 TUBE AS1
560399020 TUBE AS1
8T489621 WASHER-HARD (10.2X18.5X2.5-MM THK)4
