System And Components
385-2839 LINES GP-BLADE CYLINDER -LHS/N NFZ1-UP
Group No: 385-2839
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3995124 | 1 TUBE AS | 1 | |
| 6V0357 | 2 SEAL-O-RING | 2 | |
| 1017404 | 3 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 4 | |
| 8T0341 | 4 BOLT-SOCKET HEAD (M10X1.5X60-MM) | 4 | |
| 3995126 | 5 FLANGE | 1 | |
| 7J9108 | 6 SEAL-O-RING | 2 | |
| 3937870 | 7 CLAMP | 1 | |
| 7X0796 | 8 LOCKWASHER (10.2X18.4X2.5-MM THK) | 3 | |
| 6V5843 | 9 BOLT (M10X1.5X45-MM) | 1 | |
| 6V9831 | 10 CAP (ORFS) | 2 | |
| 4229139 | 11 SUPPORT AS | 1 | |
| 4248398 | NUT-WELD (M10X1.5-THD) | 2 | |
| 6V5842 | 12 BOLT (M10X1.5X40-MM) | 2 |
