System And Components
563-1466 LINES GP-BOOM CYLINDERS/N NFZ1-UP
Group No: 563-1466
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4186 | 1 BOLT (M10X1.5X40-MM) | 2 | |
| 8T3653 | 2 BOLT (M14X2X80-MM) | 1 | |
| 3B4509 | 3 LOCKWASHER | 1 | |
| 6V0357 | 4 SEAL-O-RING | 2 | |
| 7X0796 | 5 LOCKWASHER (10.2X18.4X2.5-MM THK) | 2 | |
| 1053478 | 6 BOLT-SOCKET HEAD (M10X1.5X35-MM) | 8 | |
| 3937898 | 7 CLAMP | 2 | |
| 5581625 | 8 TUBE AS (BOOM CYLINDER, RH)(CAP) | 1 | |
| 5581626 | 9 SUPPORT AS | 1 | |
| 5581627 | 10 SUPPORT | 1 | |
| 5631470 | 11 TUBE AS (BOOM CYLINDER, RH)(HEAD) | 1 |
