System And Components
558-1462 LINES GP-FRONTS/N NFZ1-UP
Group No: 558-1462
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P3704 | 1 SEAL-RECTANGULAR | 1 | |
| 8T4648 | 2 BOLT (M12X1.75X70-MM) | 4 | |
| 1P3703 | 3 SEAL-RECTANGULAR | 2 | |
| 5P7466 | 4 CLIP (SLOT) | 1 | |
| 5P7467 | 5 CLIP (TAB) | 1 | |
| 5P7468 | 6 CLIP (SLOT) | 1 | |
| 5P7469 | 7 CLIP (TAB) | 1 | |
| 5P8444 | 8 GROMMET (37-MM ID) | 1 | |
| 6V0400 | 9 FLANGE-HALF | 4 | |
| 7K1181 | 10 STRAP-CABLE | 2 | |
| 8T4139 | 11 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4223 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 20 | |
| 1488327 | 13 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488347 | 14 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488355 | 15 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9005 | ELBOW | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488357 | 16 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9008 | ELBOW | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 2048393 | 17 HOSE AS | 1 | |
| 5269367 | 18 VALVE GP-SOLENOID & RELIEF (CONTROL) | 1 | |
| 5618329 | 19 TUBE AS | 1 | |
| 5664218 | 20 HOSE AS | 1 | |
| 5664224 | 21 SUPPORT AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 5813168 | 22 HOSE AS | 1 | |
| 5813171 | 23 SUPPORT AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 5816651 | 24 HOSE AS | 1 | |
| 5P8112 | 25 GROMMET | 1 | |
| 8T4194 | 26 BOLT (M12X1.75X50-MM) | 10 | |
| 8T4956 | 27 BOLT (M12X1.75X35-MM) | 2 |
