580-8618 VALVE GP-MAIN CONTROLS/N NFZ1-UP

Group No: 580-8618

Part Number	Part Name	Qty
0950693	1 BOLT-SOCKET HEAD (M14X2X105-MM)	4
0951575	2 SEAL-O-RING	34
0951578	3 SEAL-O-RING	2
0951579	4 SEAL-O-RING	6
0951582	5 SEAL-O-RING	3
0951586	6 SEAL-O-RING	3
0951592	7 SEAL-O-RING	6
0951600	8 SEAL-O-RING	1
0951607	9 SEAL-O-RING	4
0951698	10 SEAL-O-RING	3
0951700	11 SEAL-O-RING	11
1076479	12 PLUG	2
1105525	13 PLUG	3
1709997	14 PLUG	6
1970145	15 PLUG	3
2019294	16 PLUG	2
2705979	17 VALVE GP-RELIEF (MAIN)	1
3099977	18 VALVE GP-RELIEF (LINE)(BOOM)	1
3099977	18A VALVE GP-RELIEF (LINE)(BUCKET)	2
3099977	18B VALVE GP-RELIEF (LINE)(UNLOAD)	1
3099977	18C VALVE GP-RELIEF (LINE)(ARM)	1
1105525	19 PLUG	15
3717201	20 PLUG	11
3903522	21 VALVE (BOOM)	1
3903522	21A VALVE (ARM)	1
3J1907	22 SEAL-O-RING	15
3K0360	23 SEAL-O-RING	1
4390578	24 BOLT (M4X0.7X8-MM)	32
5421309	25 PLUG (3/4-16-NPTF)	1
5535191	26 SPRING	2
5537330	27 SPRING	1
5847764	28 STEM AS-TRAVEL	2
5847774	SPRING-RETURN	1
5847776	RETAINER-SPRING	2
5847777	BOLT	1
5847778	SLEEVE-STEM	1
5847765	29 STEM AS-BOOM	1
5537335	RETAINER	2
5603908	BOLT-SOCKET HEAD	1
5603909	SLEEVE	1
5847772	SPRING-RETURN	1
5847766	30 STEM AS-STICK	1
5537335	RETAINER	2
5603908	BOLT-SOCKET HEAD	1
5603909	SLEEVE	1
5847773	SPRING-RETURN	1
5847767	31 STEM AS-BUCKET	1
5847774	SPRING-RETURN	1
5847776	RETAINER-SPRING	2
5847777	BOLT	1
5847778	SLEEVE-STEM	1
5847768	32 STEM AS-SWING	1
5847774	SPRING-RETURN	1
5847776	RETAINER-SPRING	2
5847777	BOLT	1
5847778	SLEEVE-STEM	1
5847769	33 STEM AS	1
5847775	SPRING-RETURN	1
5847776	RETAINER-SPRING	2
5847777	BOLT	1
5847778	SLEEVE-STEM	1
5847770	34 COVER-PILOT	2
5847771	35 COVER-PILOT	5
5847779	36 VALVE-COMPENSATOR (TRAVEL RIGHT)	1
5847779	36A VALVE-COMPENSATOR (TRAVEL LEFT)	1
5847780	37 SPRING-VALVE	2
5847781	38 PLUG	2
5847782	39 VALVE AS-CHECK (TRAVEL RIGHT)	1
5847782	39A VALVE AS-CHECK (TRAVEL LEFT)	1
5847783	40 VALVE AS-SELECTOR (BOOM)	1
5847783	40A VALVE AS-SELECTOR (ARM)	1
5847784	41 VALVE-CHECK (BOOM)	1
5847784	41A VALVE-CHECK (ARM)	1
5847785	42 SPRING-CHECK VALVE	2
5847786	43 VALVE-COMPENSATOR (UNLOAD)	1
5847787	44 SPRING-VALVE	1
5847788	45 PLUG	1
5847789	46 STEM	1
5847790	47 SPRING	1
5847791	48 WASHER	1
5847792	49 PLUG	1
5847793	50 VALVE-CHECK	1
5847794	51 VALVE-CHECK	1
5847795	52 SPRING	1
5847796	53 MANIFOLD-VALVE	1
5847797	54 MANIFOLD-VALVE	1
5847798	55 MANIFOLD-VALVE	1
5847799	56 COVER	1
5847800	57 VALVE GP-CHECK (BOOM)	2
5847801	58 SPRING-VALVE	1
5847802	59 SPRING-BYPASS VALVE	1
5847803	60 COVER	1
5847804	61 PLUG-ORIFICE	1
5847805	62 VALVE GP-RELIEF (BOOM)	1
5A3604	63 BOLT-SOCKET HEAD (M8X1.25X25-MM)	28
7I7206	64 PLUG	2
7I7207	65 SPRING	2
7I7208	66 VALVE-LOAD CHECK (BUCKET)	1
7I7208	66A VALVE-LOAD CHECK (SWING)	1
7I7235	67 PLUG	2
7I8084	68 PLUG	25
7I8935	69 BOLT-SOCKET HEAD (M8X1.25X75-MM)	1
8T0269	70 BOLT-SOCKET HEAD (M6X1X20-MM)	6
4855747	71 VALVE GP-SOLENOID (12-VOLT)(TRAVEL RIGHT)	2
4855747	71A VALVE GP-SOLENOID (12-VOLT)(TRAVEL LEFT)	3
4855747	71B VALVE GP-SOLENOID (12-VOLT)(BOOM)	2
4855747	71C VALVE GP-SOLENOID (12-VOLT)(BUCKET)	2
4855747	71D VALVE GP-SOLENOID (12-VOLT)(UNLOAD)	2
4855747	71E VALVE GP-SOLENOID (12-VOLT)(ARM)	2
4855747	71F VALVE GP-SOLENOID (12-VOLT)(SWING)	2
4910908	72 VALVE GP-SOLENOID (24-VOLT)(ON/OFF)	1
5285888	73 VALVE GP-CONTROL (TOOL CONTROL SYSTEM)	1
5061112	KIT-SEAL (SOLENOID VALVE)(SOLENOID)	1
