System And Components
525-4933 LINKAGE GP-BUCKET -CRANES/N NFZ1-UP
Group No: 525-4933
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4532841 | 1 BOLT (M16X2X150-MM) | 1 | |
| 3B8489 | 2 FITTING-GREASE (1/8-27 PTF) | 5 | |
| 7I6843 | 3 PIN | 1 | |
| 0860523 | 4 PIN | 2 | |
| 5948810 | 5 NUT (M14X2-THD) | 6 | |
| 1661482 | 6 SHIM (2-MM THK) | 2 | |
| 2357679 | 7 SEAL-LIP TYPE | 4 | |
| 2487820 | 8 PIN | 1 | |
| 2487822 | 9 LINK | 1 | |
| 2487823 | 10 LINK AS | 1 | |
| 2487836 | 11 SEAL-LIP TYPE | 2 | |
| 3312025 | 12 HOOK GP-LIFTING | 1 | |
| 3678465 | 13 SEAL-O-RING | 4 | |
| 4512183 | 14 NUT (M16X2-THD) | 2 | |
| 4838105 | 15 LOCK AS | 1 | |
| 5271076 | 16 LINK & BEARING AS | 1 | |
| 5176017 | 16A BEARING-SLEEVE | 2 | |
| 5176019 | 16B BEARING-SLEEVE | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 0990707 | 17 BOLT (M14X2X115-MM) | 1 | |
| 0990724 | 18 BOLT (M14X2X145-MM) | 2 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 20 BOLT (M10X1.5X25-MM) | 4 |
