System And Components
388-6156 COUPLER GP-QUICK -312-LINKAGES/N NFZ1-UP
Group No: 388-6156
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5B0935 | 1 FITTING-GREASE | 8 | |
| 1598036 | 3 FILM-WARNING (READ OMM) | 1 | |
| 3555804 | 4 PLUG | 2 | |
| 3880105 | 5 HOSE AS | 2 | |
| 3880110 | 6 HOSE AS | 1 | |
| 3880109 | 7 HOSE AS | 1 | |
| 3886177 | 8 PIN | 1 | |
| 3886178 | 9 PIN | 1 | |
| 3914597 | 10 ROCKER ARM (RH) | 1 | |
| 3914598 | 11 ROCKER ARM (LH) | 1 | |
| 3914599 | 12 LATCH | 1 | |
| 3949469 | 13 PIN | 1 | |
| 5697997 | 14 CYLINDER GP-COUPLER (312-LINKAGE) | 1 | |
| 4189163 | 15 SPRING-SPACER | 2 | |
| 4189164 | 16 SPRING-GUIDE | 2 | |
| 4246686 | 17 SPRING | 2 | |
| 4405314 | 18 HOSE AS | 1 | |
| 4405315 | 19 HOSE AS | 1 | |
| 4492856 | 20 WEDGE | 1 | |
| 4498112 | 21 PIN | 1 | |
| 4592215 | 24 PLATE-COVER | 1 | |
| 4592216 | 25 PIN | 1 | |
| 0950933 | 26 RING-RETAINING | 2 | |
| 2P1279 | 27 LOCKNUT (9/16-18-THD) | 2 | |
| 2W5975 | 28 SCREW-BOLT (1/4-28X0.5-IN) | 1 | |
| 3J1907 | 29 SEAL-O-RING | 1 | |
| 3J7354 | 30 SEAL-O-RING | 1 | |
| 4D1322 | 31 RING-RETAINING | 2 | |
| 4D7794 | 32 CLIP | 1 | |
| 4J5477 | 33 SEAL-O-RING | 3 | |
| 4M8973 | 34 ELBOW | 1 | |
| 6J7836 | 35 RING-SNAP | 2 | |
| 8C3312 | 36 RING-RETAINING | 4 | |
| 6V8397 | 37 SEAL-O-RING | 3 | |
| 6V8636 | 38 CONNECTOR | 1 | |
| 6V8647 | 39 CONNECTOR | 1 | |
| 6V8979 | 40 ELBOW | 1 | |
| 6V8980 | 41 ELBOW | 1 | |
| 6V9168 | 42 NUT (11/16-16-THD) | 2 | |
| 6V9828 | 43 CAP (ORFS) | 1 | |
| 6V9829 | 44 CAP (ORFS) | 1 | |
| 8L5008 | 46 ELBOW-PIPE | 1 | |
| 8T4121 | 47 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4136 | 48 BOLT (M10X1.5X25-MM) | 5 | |
| 8T4137 | 49 BOLT (M10X1.5X20-MM) | 1 | |
| 9S4185 | 50 PLUG (3/4-16-THD) | 2 | |
| 5680343 | 51 CONTROL GP-ELECTRONIC (WORK TOOL) | 1 | |
| 4339730 | 52 FILM-WARNING (EXPLOSION, WIRELESS, OMM, INTL) | 1 | |
| 4592208 | 53 COUPLER AS | 1 | |
| 9R2613 | BOSS-WELD (M10X1.5X25-MM) | 1 | |
| 4750019 | PIN | 12 | |
| 4767093 | PIN | 4 | |
| 5585895 | PLATE | 1 | |
| 4583275 | 54 PLATE | 1 |
