System And Components
169-0701 LOCK GP-QUICK COUPLER -HYDRAULICS/N NFZ1-UP
Group No: 169-0701
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1690700 | 1 WEDGE | 1 | |
| 1656005 | 2 SHAFT | 2 | |
| 1656006 | 3 SPRING | 2 | |
| 1656007 | 4 RING | 2 | |
| 0990169 | 5 BOLT (M16X2X55-MM) | 2 | |
| 1677782 | 6 PLATE | 2 | |
| 1688242 | 7 RING | 2 | |
| 1687790 | 8 BOLT (M20X2.5X130-MM) | 2 | |
| 1690328 | 9 SPACER (22X38X67-MM THK) | 2 | |
| 9X8257 | 10 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 1690329 | 11 CYLINDER GP-COUPLER | 1 | |
| 8T4223 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4183 | 13 BOLT (M12X1.75X40-MM) | 4 | |
| 0985747 | 14 NUT (M16X2-THD) | 2 | |
| 0950703 | 15 BOLT-SOCKET HEAD (M16X2X75-MM) | 1 |
