System And Components
525-9175 CONTROL GP-BLADES/N NFZ1-UP
Group No: 525-9175
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1282135 | 1 SCREW-TRUSS HEAD (M6X1X13-MM) | 1 | |
| 1785528 | 2 KNOB | 1 | |
| 5164950 | 3 BRACKET AS | 1 | |
| 5C2890 | NUT (M6X1-THD) | 5 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 5164965 | 4 LEVER AS (BLADE) | 1 | |
| 5208238 | 5 SHEET | 1 | |
| 5636865 | 6 BRACKET AS | 1 | |
| 5C2890 | NUT (M6X1-THD) | 1 | |
| 5662153 | 7 COVER-VALVE | 1 | |
| 5662154 | 8 BRACKET | 1 | |
| 5662156 | 9 COVER-BLOCK | 1 | |
| 5682461 | 10 BASE AS | 1 | |
| 2610525 | RECEPTACLE AS-CONNECTOR (4-PIN) | 1 | |
| 5682462 | 11 BOOT | 1 | |
| 5682465 | 12 RING | 1 | |
| 5C7261 | 13 NUT (M8X1.25-THD) | 1 | |
| 8T4224 | 14 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 9X2044 | 15 SCREW-TRUSS HEAD (M6X1X16-MM) | 5 | |
| 9X2045 | 16 SCREW-TRUSS HEAD (M6X1X20-MM) | 6 |
