575-4534 LINES GP-AIR CONDITIONERS/N NFZ1-UP

Group No: 575-4534

Part Number	Part Name	Qty
1004336	1 CLIP (LOOP)	7
1087553	2 GROMMET	1
1229657	3 CLAMP	2
2041611	4 STRAP-CABLE (DUAL)	1
2358891	5 PLATE	1
2359014	6 CLAMP-SPRING	4
2609144	7 CONNECTOR AS	1
3K0360	SEAL-O-RING	1
1688806	CONNECTOR	1
2667379	8 STRAP-CABLE	1
2931238	9 HOSE-DRAIN	1
3048028	10 CONNECTOR AS	1
3K0360	SEAL-O-RING	1
3048027	ADAPTER	1
3050441	11 BAND-MARKER (HS)	2
3050442	12 BAND-MARKER (HR)	2
3729319	13 HOSE-DRAIN	1
3920808	14 ELBOW AS	1
5P4906	ELBOW	1
6V6609	SEAL-O-RING	1
3S2093	15 STRAP-CABLE	2
3023908	16 SPACER (11X20X30-MM THK)	1
4841456	17 STRAP-CABLE	4
5001004	18 SUPPORT AS	1
8T3490	NUT-WELD (M10X1.5-THD)	1
1787023	BOSS (M10X1.5X30-MM)	2
5416629	19 CLIP (LOOP)	3
5540012	20 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	1
5662229	21 HOSE AS	1
1217136	SEAL-O-RING	2
5744760	22 HOSE AS	1
1217137	SEAL-O-RING	2
5750559	PLUG	1
5754535	23 CONDENSER & MTG GP-REFRIGERANT	1
5754558	24 HOSE AS	1
1217136	SEAL-O-RING	1
5750560	PLUG	1
5754560	25 HOSE AS	1
1217138	SEAL-O-RING	2
5750561	SWITCH AS-PRESSURE	1
1858293	SEAL-O-RING	1
5P9297	27 CLIP (LOOP)	1
6D1641	28 CLIP (LOOP)	2
6V7357	29 BOLT (M6X1X25-MM)	3
8T4121	30 WASHER-HARD (11X21X2.5-MM THK)	16
8T4136	31 BOLT (M10X1.5X25-MM)	2
8T4137	32 BOLT (M10X1.5X20-MM)	13
8T4224	33 WASHER-HARD (8.8X16X2-MM THK)	2
8T6466	34 BOLT (M10X1.5X60-MM)	1
8T7547	35 BOLT (M8X1.25X30-MM)	2
9X8256	36 WASHER (6.6X12X2-MM THK)	3
2667379	37 STRAP-CABLE	2
3S2093	38 STRAP-CABLE	2
5P0767	39 HOSE (291-CM)
5P0767	39A HOSE (181-CM)
5767677	PLATE GP-CERTIFICATION	1
