System And Components
477-7563 WINDOW GP-CAB -FRONTS/N NFZ1-UP
Group No: 477-7563
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E8020 | 1 SCREW-TRUSS HEAD (M6X1X25-MM) | 2 | |
| 1091393 | 2 BOLT-SOCKET HEAD (M4X0.7X10-MM) | 1 | |
| 1519557 | 3 STOP-RUBBER | 2 | |
| 3346499 | 4 BRACKET AS | 1 | |
| 4305703 | 5 SHIM (2-MM THK) | 1 | |
| 4848019 | 6 WINDOW GP-CAB (FRONT, UPPER) | 1 | |
| 4886492 | 7 WINDOW GP-CAB (FRONT, LOWER) | 1 | |
| 4886529 | 8 BRACKET AS | 1 | |
| 4886546 | 9 CABLE AS | 1 | |
| 4886548 | 10 SWITCH AS-CONTROL | 1 | |
| 4886582 | 11 BRACKET AS | 1 | |
| 4886583 | 12 BRACKET AS | 1 | |
| 4987783 | 13 BRACKET | 1 | |
| 5000740 | 14 BRACKET | 2 | |
| 5000791 | 15 SEAL | 1 | |
| 5115969 | 16 BUMPER | 2 | |
| 5268616 | 17 SHIM (2-MM THK) | 2 | |
| 5389725 | 18 COVER | 1 | |
| 5389803 | 19 BRACKET | 1 | |
| 0964007 | 20 SPACER (8.2X18X0.5-MM THK) | 6 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 22 NUT (M10X1.5-THD) | 2 | |
| 9X2042 | 23 SCREW-TRUSS HEAD (M6X1X12-MM) | 14 | |
| 9X2044 | 24 SCREW-TRUSS HEAD (M6X1X16-MM) | 6 | |
| 5P4116 | 25 WASHER-HARD (8.8X20.5X2-MM THK) | 8 |
