System And Components
559-1095 WIPER GP-WINDOW -LOWERS/N NFZ1-UP
Group No: 559-1095
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 1 | |
| 4I3090 | 2 SEAL | 1 | |
| 8T4121 | 3 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4189 | 4 BOLT (M8X1.25X20-MM) | 3 | |
| 8T4196 | 5 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4224 | 6 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 9X2044 | 7 SCREW-TRUSS HEAD (M6X1X16-MM) | 2 | |
| 1189901 | 8 SPACER (12X20X10-MM THK) | 2 | |
| 1613128 | 9 RELAY (24-VOLT)(WIPER MOTOR) | 1 | |
| 5268603 | 10 BLADE AS-WIPER (LOWER) | 1 | |
| 1636795 | 11 STRAP-CABLE | 2 | |
| 4I1163 | 12 BRACKET | 1 | |
| 5268602 | 13 ARM AS-WIPER | 1 | |
| 5717235 | 14 BRACKET AS | 1 | |
| 5717250 | 15 SUPPORT AS | 1 | |
| 5480092 | LINER | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 3 | |
| 5744743 | 16 COVER AS | 1 | |
| 5758670 | 17 MOTOR AS-WINDOW WIPER | 1 | |
| 9X8256 | 18 WASHER (6.6X12X2-MM THK) | 4 |
