System And Components
521-6362 LINES GP-FUELS/N JPC1-UP
Group No: 521-6362
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2287100 | 1 SEAL-O-RING | 1 | |
| 8T4196 | 2 BOLT (M10X1.5X35-MM) | 9 | |
| 0963872 | 3 GROMMET | 1 | |
| 1334419 | 4 GROMMET | 2 | |
| 1833399 | 5 CONNECTOR AS | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 1911782 | 6 SPACER (8.5X12.7X38.2-MM THK) | 1 | |
| 2147566 | 7 SEAL-O-RING | 1 | |
| 2287089 | 8 SEAL-O-RING | 1 | |
| 2287091 | 9 SEAL-O-RING | 1 | |
| 2751442 | 10 CLIP (TAB) | 2 | |
| 2751443 | 11 CLIP (SLOT) | 2 | |
| 2751444 | 12 GROMMET | 2 | |
| 2815977 | 13 CONNECTOR AS | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3072673 | 14 PLUG AS | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3095131 | 15 PLUG AS | 3 | |
| 9S8006 | PLUG (7/8-14-THD) | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3095146 | 16 ADAPTER | 1 | |
| 3328593 | 17 VALVE AS-BALL (FUEL SHUTOFF) | 1 | |
| 1562525 | VALVE-SHUTOFF | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3432385 | 18 CLIP (LOOP) | 2 | |
| 3474416 | 19 ADAPTER | 2 | |
| 3514315 | 20 CLIP (LOOP) | 4 | |
| 3514318 | 21 CLIP (LOOP) | 2 | |
| 3514320 | 22 CLIP (LOOP) | 17 | |
| 3514321 | 23 CLIP (LOOP) | 8 | |
| 3514336 | 24 GROMMET | 2 | |
| 3535143 | 25 ADAPTER AS | 1 | |
| 6V5653 | ELBOW (7/8-14-THD) | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3535150 | 26 CONNECTOR AS | 1 | |
| 8T1576 | CONNECTOR | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 3535441 | 27 ADAPTER-ELBOW | 1 | |
| 3872660 | 28 CLIP | 2 | |
| 3S2093 | 29 STRAP-CABLE | 1 | |
| 4236434 | 30 SENSOR GP-LIQUID LEVEL (WATER IN FUEL) | 1 | |
| 4334617 | 31 PLATE AS | 1 | |
| 4343926 | 32 BASE GP-FUEL FILTER | 1 | |
| 4391960 | 33 ADAPTER AS | 2 | |
| 1688806 | CONNECTOR | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 4675167 | 34 SPACER | 2 | |
| 4675344 | 35 MOUNT | 6 | |
| 3023908 | 36 SPACER (11X20X30-MM THK) | 1 | |
| 4I0379 | 37 VALVE-MANUAL (FUEL) | 1 | |
| 5017449 | 38 ADAPTER AS | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 5042756 | ADAPTER | 1 | |
| 5078356 | 39 CONNECTOR AS | 1 | |
| 1433158 | CONNECTOR | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 5216163 | 40 PUMP GP-FUEL PRM & PRIM FILTER | 1 | |
| 5243798 | 41 CONNECTOR AS | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 5243797 | CONNECTOR | 1 | |
| 5249278 | 42 FITTING AS | 1 | |
| 2385081 | SEAL-O-RING | 1 | |
| 5249277 | FITTING | 1 | |
| 3478647 | 43 HOSE (180-CM) | ||
| 5826399 | 44 HOSE AS | 1 | |
| 3478646 | HOSE (236-CM) | ||
| 4252633 | CONNECTOR-SPECIAL | 1 | |
| 5826400 | 45 HOSE AS | 1 | |
| 3478646 | HOSE (288-CM) | ||
| 4252633 | CONNECTOR-SPECIAL | 1 | |
| 5826401 | 46 HOSE AS | 1 | |
| 3478646 | HOSE (347-CM) | ||
| 5251568 | 48 LINER | 1 | |
| 5251569 | 49 LINER | 1 | |
| 5332245 | 50 SENSOR AS-PRESSURE (FUEL PRIMING PUMP) | 1 | |
| 5682872 | 51 PLATE AS | 1 | |
| 5682879 | 52 PLATE AS | 1 | |
| 5682881 | 53 HOSE AS | 1 | |
| 5682882 | 54 HOSE AS | 1 | |
| 5682892 | 55 HOSE AS | 1 | |
| 5692243 | 56 PLATE AS | 1 | |
| 5714696 | 57 PLATE AS | 1 | |
| 5714706 | 58 PLATE AS | 1 | |
| 5I3876 | 59 GROMMET | 1 | |
| 5I8307 | 60 GROMMET | 2 | |
| 5P7462 | 61 CLIP (SLOT) | 2 | |
| 5P7463 | 62 CLIP (TAB) | 2 | |
| 5P7464 | 63 CLIP (SLOT) | 1 | |
| 5P7465 | 64 CLIP (TAB) | 1 | |
| 5V9155 | 65 CLAMP-HOSE | 3 | |
| 6S8620 | 66 CLAMP-HOSE | 6 | |
| 6V0683 | 67 GROMMET | 2 | |
| 6V1249 | 68 GROMMET (22-MM ID) | 1 | |
| 2041611 | 69 STRAP-CABLE (DUAL) | 1 | |
| 7X0579 | 70 WASHER-HARD (8.8X25.5X2-MM THK) | 6 | |
| 7X2540 | 71 BOLT (M8X1.25X120-MM) | 2 | |
| 8T4121 | 72 WASHER-HARD (11X21X2.5-MM THK) | 55 | |
| 8T4133 | 73 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 74 BOLT (M10X1.5X25-MM) | 38 | |
| 8T4137 | 75 BOLT (M10X1.5X20-MM) | 3 | |
| 8T6466 | 76 BOLT (M10X1.5X60-MM) | 1 | |
| 8T6869 | 77 BOLT (M8X1.25X60-MM) | 1 | |
| 3478646 | 78 HOSE (44-CM) | ||
| 3478646 | 78A HOSE (439-CM) | ||
| 3478645 | 79 HOSE (181-CM) | ||
| 3478645 | 79A HOSE (35-CM) | ||
| 3196217 | 80 CONNECTOR AS | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3196240 | 81 CONNECTOR AS | 2 | |
| 6V9873 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2147568 | SEAL-O-RING | 1 |
