System And Components
511-6024 CONSOLE GP -LHS/N JPC1-UP
Group No: 511-6024
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4876653 | 1 COVER AS | 1 | |
| 4876654 | 2 COVER AS | 1 | |
| 2346579 | NUT-SPEED | 1 | |
| 5115919 | CLIP | 5 | |
| 4876832 | 3 COVER | 1 | |
| 4876838 | 4 COVER | 1 | |
| 4987728 | 5 COVER AS | 1 | |
| 5115982 | COVER | 3 | |
| 5000930 | 6 COVER AS-CONSOLE | 1 | |
| 4876652 | COVER AS | 1 | |
| 4876829 | COVER | 1 | |
| 5115919 | CLIP | 4 | |
| 5389680 | GUIDE | 1 | |
| 5330365 | CLIP | 4 | |
| 4876828 | COVER | 1 | |
| 5000933 | 7 SUPPORT AS (LH) | 1 | |
| 5115921 | 8 BAR AS | 1 | |
| 5682312 | 9 HANDLE AS | 1 | |
| 5116004 | 10 BRACKET AS | 1 | |
| 5116025 | 11 LEVER AS | 1 | |
| 4I3038 | WASHER (3.3X8X0.5-MM THK) | 2 | |
| 1114799 | SWITCH AS-LIMIT (HYDRAULIC LOCKOUT) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 3E3371 | WEDGE-RECEPTACLE LOCK (3-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 5P5998 | TUBE (0.3-M) | ||
| 1209027 | SCREW-PAN HEAD (M3X0.5X16-MM) | 2 | |
| 5164930 | 12 COVER | 1 | |
| 5208227 | 13 SCREW-MACHINE (M4X0.7X2.3-MM) | 1 | |
| 5208253 | 14 SCREW-TAPPING | 2 | |
| 5662193 | 15 SCREW-MACHINE (M4X0.7X10-MM) | 3 | |
| 5208291 | 16 SCREW-MACHINE (M4X0.7X15-MM) | 2 | |
| 5208292 | 17 SPACER (4.2X6X3.3-MM THK) | 2 | |
| 5268631 | 18 RIVET | 1 | |
| 9X2042 | 19 SCREW-TRUSS HEAD (M6X1X12-MM) | 3 | |
| 9X2043 | 20 SCREW-TRUSS HEAD (M6X1X14-MM) | 2 |
