System And Components
563-6861 CONSOLE GP-OPERATORS/N JPC1-UP
Group No: 563-6861
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3T0849 | 1 BOLT-SOCKET HEAD (M6X1X25-MM) | 6 | |
| 7Y8561 | 2 BUMPER | 1 | |
| 8T4121 | 3 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4133 | 4 NUT (M10X1.5-THD) | 1 | |
| 9X2043 | 5 SCREW-TRUSS HEAD (M6X1X14-MM) | 6 | |
| 9X6165 | 6 WASHER (6.5X22X2.5-MM THK) | 4 | |
| 9X8256 | 7 WASHER (6.6X12X2-MM THK) | 6 | |
| 3320195 | 8 CLIP | 2 | |
| 4886551 | 9 CONSOLE GP-OPERATOR (STORAGE) | 1 | |
| 4886570 | 10 CONSOLE GP-OPERATOR (SECONDARY) | 1 | |
| 4956057 | 11 BUSHING | 6 | |
| 5116016 | 12 CONSOLE GP-OPERATOR (RH) | 1 | |
| 5208286 | 13 STRIKER | 1 | |
| 5208293 | 14 SPACER (18.5X34X3.1-MM THK) | 1 | |
| 5208294 | 15 BRACKET | 2 | |
| 4876659 | 16 ARMREST GP (DELUXE) | 1 | |
| 4878455 | 17 CONTROL GP-JOYSTICK (LOW FORCE) | 2 | |
| 5000884 | 18 DAMPER | 1 | |
| 5116023 | 19 CONSOLE GP-OPERATOR (LH) | 1 |
