486-5504 CONTROL & MTG GP-PEDALS/N JPC1-UP
Group No: 486-5504
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1017401 | 1 BOLT-SOCKET HEAD (M10X1.5X20-MM) | 4 | |
| 1176356 | 2 STEP AS | 2 | |
| 1229608 | 3 PEDAL-RUBBER (RH) | 1 | |
| 1229609 | 4 PEDAL-RUBBER (LH) | 1 | |
| 1229610 | 5 STEP | 2 | |
| 5937293 | 6 KNOB | 2 | |
| 1709498 | 7 LEVER AS (RH) | 1 | |
| 1709499 | 8 LEVER AS (LH) | 1 | |
| 4886458 | 9 PEDAL AS (LH) | 1 | |
| 4886459 | 10 PEDAL AS (RH) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 5617001 | 11 CONTROL GP-PEDAL | 1 | |
| 5093085 | BOOT | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 6 | |
| 1519275 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 5093087 | DAMPER AS | 1 | |
| 5268624 | 12 PLATE | 2 | |
| 0966166 | 13 WASHER-HARD (4.5X9X1-MM THK) | 2 | |
| 8T0337 | 14 SCREW-MACHINE (M4X0.7X12-MM) | 2 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4136 | 16 BOLT (M10X1.5X25-MM) | 8 | |
| 8T4191 | 17 BOLT (M10X1.5X16-MM) | 4 | |
| 9X2027 | 18 WASHER (11X18X2-MM THK) | 4 |
