System And Components
550-9988 TURBOCHARGER GPS/N J4A1-UP
Group No: 550-9988
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1142583 | 1 STUD (M8X1.25X37-MM) | 4 | |
| 3484636 | 2 STUD (M10X1.5X70-MM) | 4 | |
| 1004454 | 3 NUT (M8X1.25-THD) | 4 | |
| 3435910 | 4 CLAMP-V BAND | 1 | |
| 3487736 | 5 GASKET | 1 | |
| 3672071 | 6 CLAMP | 1 | |
| 5372001 | 7 COUPLING AS | 1 | |
| 2722583 | 7A SEAL-O-RING | 1 | |
| 2256948 | 7B SEAL-O-RING | 1 | |
| 5403647 | 8 SEAL | 1 | |
| 5620360 | 9 PIPE AS | 1 | |
| 6I4045 | 10 BOLT (M10X1.5X75-MM) | 4 | |
| 5672084 | 11 BRACKET | 1 | |
| 5642453 | 12 DUCT | 1 | |
| 5733591 | 14 TURBOCHARGER AS | 1 | |
| 5668180 | 15 TURBOCHARGER AS | 1 | |
| 6I0260 | 17 BOLT (M8X1.25X25-MM) | 3 | |
| 6I0563 | 18 NUT (M10X1.5-THD) | 4 | |
| 5612101 | KIT-TURBOCHARGER | 1 | |
| 5612443 | KIT-TURBOCHARGER ACTUATOR | 1 | |
| 5612444 | KIT-ROD | 1 |
