System And Components
590-1492 LINES GP-BOOM -MASSS/N JNF1-UP
Group No: 590-1492
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4184 | 1 BOLT (M12X1.75X45-MM) | 8 | |
| 8T4910 | 2 BOLT (M12X1.75X60-MM) | 2 | |
| 8T4648 | 3 BOLT (M12X1.75X70-MM) | 2 | |
| 8T6868 | 4 BOLT (M12X1.75X80-MM) | 2 | |
| 0931292 | 5 CLAMP | 2 | |
| 0931295 | 6 CLAMP | 2 | |
| 0938885 | 7 VALVE GP-FLOW CONTROL | 1 | |
| 0951592 | 8 SEAL-O-RING | 4 | |
| 0997026 | 9 VALVE GP-SHUTOFF | 1 | |
| 1488327 | 10 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488347 | 11 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1579338 | 12 PLATE | 1 | |
| 1662980 | 13 BLOCK | 1 | |
| 2026996 | 14 HOSE AS | 1 | |
| 3075253 | 15 HOSE AS | 1 | |
| 5932206 | 16 TUBE AS | 1 | |
| 5932207 | 17 TUBE AS | 1 | |
| 5932208 | 18 TUBE AS | 1 | |
| 5932209 | 19 TUBE AS | 1 | |
| 5932210 | 20 TUBE AS | 1 | |
| 5932211 | 21 TUBE AS | 1 | |
| 5932212 | 22 TUBE AS | 1 | |
| 5932213 | 23 TUBE AS | 1 | |
| 1P3703 | 24 SEAL-RECTANGULAR | 2 | |
| 1R9072 | 25 JOINT | 4 | |
| 4I1674 | 26 CLIP | 4 | |
| 4I1676 | 27 CLIP | 4 | |
| 6V0400 | 28 FLANGE-HALF | 4 | |
| 6V9746 | 29 SEAL-O-RING | 11 | |
| 7Y4868 | 30 CLIP | 14 | |
| 8T4139 | 31 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4223 | 32 WASHER-HARD (13.5X25.5X3-MM THK) | 28 | |
| 3621320 | 33 BOLT (M12X1.75X35-MM) | 10 |
