System And Components
253-0312 LINES GP-CYLINDER -BOOM CYLINDERS/N A3L1-UP
Group No: 253-0312
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1511751 | 1 HOSE AS | 4 | |
| 9F2167 | 2 SCREW-PURGE (3/8-24X1.164-IN) | 2 | |
| 1021174 | 3 GUARD | ||
| 1319547 | 4 CLIP | 1 | |
| 1319548 | 5 SUPPORT AS | 1 | |
| 2489461 | 6 SUPPORT AS | 1 | |
| 2344492 | 7 SUPPORT | 1 | |
| 2455065 | 8 TUBE AS | 1 | |
| 2614987 | 9 TUBE AS | 1 | |
| 1P3703 | 10 SEAL-RECTANGULAR | 2 | |
| 1087550 | 11 CLIP | 2 | |
| 5K9090 | 12 SEAL-O-RING | 4 | |
| 5P1076 | 13 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 6V0400 | 14 FLANGE-HALF | 8 | |
| 8T4648 | 15 BOLT (M12X1.75X70-MM) | 4 | |
| 8T4139 | 16 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4183 | 17 BOLT (M12X1.75X40-MM) | 8 | |
| 8T4184 | 18 BOLT (M12X1.75X45-MM) | 16 | |
| 8T4223 | 19 WASHER-HARD (13.5X25.5X3-MM THK) | 22 |
