Assembly
100%

296-4649 HOUSING GP-FRONTS/N GDC1-UP

Group No: 296-4649
Part NumberPart NameQty
22282921 POINTER1
29417312 BOLT (M8X1.25X19.5-MM)1
6V82363 PIN-SPRING1
29417324 PLATE1
6V52155 BOLT (M8X1.25X16-MM)2
29776466 BOLT (M8X1.25X95.5-MM)2
17865387 COVER AS1
5I55978 BOLT (M10X1.5-THD)6
5I76109 BOLT (M10X1.5X20-MM)1
297764710 BOLT (M10X1.5X77-MM)6
8T417211 BOLT (M10X1.5X80-MM)2
8T668512 BOLT (M10X1.5X110-MM)4
7X079613 LOCKWASHER (10.2X18.4X2.5-MM THK)6
294173314 GASKET1
294173415 GASKET1
212857116 COVER1
212857217 GASKET1
196836618 BOLT1
294173519 BOLT (M8X1.25X90.5-MM)5
294725120 BOLT AS6
294172621 BOLT (M10X1.5X37-MM)4
096943522 PLUG1
096953223 WASHER (15.8X22.5X2-MM THK)1
096952824 SEAL-O-RING1
6F755625 COVER2
5I763226 PIPE1
294172727 BODY AS1
294172827A GEAR (32-TEETH)1
125295027B GEAR AS (9-TEETH)1
1958225CAP (MAIN BEARING)1
5I755928 VALVE AS1
5I755829 GEAR AS (9-TEETH)1
294172930 GEAR AS (33-TEETH)1
324422331 SEAL1
6F755732 GASKET2
5I768333 SPINDLE1
178653734 GASKET1
