System And Components
273-7735 LINES GP-FUELS/N CYZ307-395
Group No: 273-7735
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I0379 | 1 VALVE-MANUAL (DRAIN, FUEL TANK) | 1 | |
| 5P7175 | 2 FITTING-STRAIGHT | 1 | |
| 0037764 | 3 END-HOSE | 2 | |
| 0951386 | 4 CLAMP-HOSE | 9 | |
| 1503024 | 5 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5P4924 | ELBOW | 1 | |
| 1702901 | 6 GROMMET | 1 | |
| 1749570 | 7 FILTER GP-WATER SEP & FUEL (PRIMARY) | 1 | |
| 1779778 | 8 BASE AS | 1 | |
| 9S4167 | STUD-HOLLOW (1-14X1.47-IN) | 1 | |
| 2553160 | 9 HOSE | 1 | |
| 2866186 | 10 SHEET AS | 1 | |
| 2936789 | 11 BRACKET AS | 1 | |
| 2983147 | 12 VALVE GP-FUEL SHUTOFF | 1 | |
| 1343299 | 13 GROMMET | 1 | |
| 2R1498 | 14 GROMMET | 3 | |
| 3J1907 | 15 SEAL-O-RING | 5 | |
| 5K8451 | 16 CLIP (LOOP) | 13 | |
| 7Y8167 | 17 GROMMET (50-MM ID) | 1 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 32 | |
| 8T4133 | 19 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 20 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 21 BOLT (M10X1.5X20-MM) | 22 | |
| 1358572 | 22 BOLT AS | 1 | |
| 8T4195 | 23 BOLT (M10X1.5X30-MM) | 5 | |
| 6D4636 | 24 CLIP (LOOP) | 3 | |
| 9M8406 | 25 CLIP (LOOP) | 8 | |
| 9S8004 | 26 PLUG (9/16-18-THD) | 5 | |
| 5P1442 | 27 HOSE (30-CM) | ||
| 5P1442 | 27A HOSE (161-CM) | ||
| 5P1442 | 27B HOSE (519-CM) | ||
| 3077804 | 29 HOSE AS | 1 | |
| 3077803 | 30 HOSE AS | 1 | |
| 4I9521 | 31 BAND-MARKER (RED, L1) | 2 |
