Assembly
100%

291-7744 BATTERY & WIRING GP -COLD WEATHERS/N CYZ1-UP

Group No: 291-7744
Part NumberPart NameQty
5I82701 COVER-BATTERY1
6W60052 HOLD-DOWN-BATTERY1
26395743 BATTERY AS (12-VOLT, MAINTENANCE FREE)4
17069294 CABLE AS1
5P0761CABLE (00-GA, RED)(31-CM)
9G0002COVER AS-TERMINAL (RED)1
8L8413STRAP-CABLE (WHITE)1
9G0005COVER AS-TERMINAL (BLACK)1
8L8413STRAP-CABLE (WHITE)1
8C5918TERMINAL AS-BATTERY (NEGATIVE)1
8T9756TERMINAL AS-BATTERY (POSITIVE)1
1M6119BOLT (5/16-18X1.375-IN)1
1M6120NUT (5/16-18-THD)1
23825015 KNOB1
23825286 ROD1
25952297 CABLE AS1
1S7252TERMINAL-CABLE (00-GA, 3/8-IN SCREW)1
5P0747CABLE (00-GA, BLACK)(89-CM)
9G0003COVER AS-TERMINAL (BLACK)1
8L8413STRAP-CABLE (WHITE)1
8T9757TERMINAL AS-BATTERY (NEGATIVE)1
1M6119BOLT (5/16-18X1.375-IN)1
1M6120NUT (5/16-18-THD)1
28965548 SHEET AS-SOUND SUPPRESSION1
29178769 SUPPORT AS1
299258510 CABLE AS1
1S7252TERMINAL-CABLE (00-GA, 3/8-IN SCREW)1
5P0761CABLE (00-GA, RED)(278-CM)
6V2722TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M)
9G0004COVER AS-TERMINAL (RED)1
8L8413STRAP-CABLE (WHITE)1
8C5917TERMINAL AS-BATTERY (POSITIVE)1
1M6119BOLT (5/16-18X1.375-IN)1
1M6120NUT (5/16-18-THD)1
4K886411 CLIP (LOOP)3
5C726112 NUT (M8X1.25-THD)1
6K817813 CLIP (LOOP)2
8T412114 WASHER-HARD (11X21X2.5-MM THK)1
8T413315 NUT (M10X1.5-THD)1
8T419116 BOLT (M10X1.5X16-MM)1
8T419217 BOLT (M12X1.75X25-MM)4
8T422318 WASHER-HARD (13.5X25.5X3-MM THK)4
8T422619 WASHER-PLATED (10.5X45X3-MM THK)1
